To change the IP address:
1.
Press COMM button. Rotate Voltage Encoder until IP appears on the Voltage display, 1
appears on the Current display.
2.
Press Current encoder to enter IP configuration. Rotate Voltage encoder to view the IP
address. Voltage display shows IP1-IP4 by rotating Voltage encoder. The Current display
shows the corresponding IP address.
3.
Rotate Current encoder to change the IP address. Press Current encoder to acknowledge new
IP address.
4.
If another device is using the same address, the Front Panel display and the rear LAN status
LED (Green) blinks. The address reverts to the previously set address.
5.
Press any button or encoder to stop blinking.
1. Modifying the IP address via the Front Panel, a command, or (LAN>Configure>Modify Page),
switches to STATIC IP addressing. (DHCP and Auto-IP addressing is disabled).
2. Refer to SYSTem[:COMMunicate]:LAN:IP <SRD> command to modify the IP address by
communication.
4.7.5.3
LAN Reset
To reset the power supply LAN settings to its factory settings, perform the following steps:
1.
Press the COMM button.
2.
Rotate Voltage Encoder until LAN appears on the Voltage display, RESET appears on the
Current display. Press Current encoder.
3.
SURE appears on the Voltage display, NO appears on the Current display. Rotate current
encoder 1 click clockwise. YES appears on the Current display.
4.
Press Current encoder to reset LAN configuration to factory default settings.
The default LAN settings are:
•
DHCP is enabled
•
If DHCP fails to get a lease, the auto-IP settings will be obtained:
IP address:
Subnet mask:
Default gateway
DNS Server
Hostname:
Description
Controller Access:
Ping Server:
NOTES
169.254.xxx.xxx
255.255.0.0
0.0.0.0
0.0.0.0
Refer to section 4.7.4.5
Refer to section 4.7.4.6
One Client Only
Enabled
66
