4.2.5
Baud Rate Setting
Five optional rates are possible: 9600, 19200, 38400, 57600 and 115200.
1.
Press the COMM button.
COMM LED illuminates. INTFC message appears on the Voltage display.
2.
Rotate the Voltage encoder 2 steps clockwise *.
BAUD message appears on the Voltage display.
3.
Rotate the Current encoder to select required baud rate: 9600, 19200, 38400, 57600 or 115200 **.
4.
Press the Current encoder to accept a parameter.
When the parameter is accepted, the display blinks once.
5.
To exit the menu, press the COMM button or the BACK button.
* If LAN interface is active, rotate the Voltage encoder 5 steps clockwise.
** If LAN interface is active, baud rate is locked to 115200.
4.2.6
Language Selection (RS232/RS485, USB)
power supply Series implement the SCPI standard interface to control the unit by
remote communication. In addition, GEN legacy commands subset is provided for ease of use and
backward compatibility.
1.
Press the COMM button.
COMM LED illuminates. INTFC message appears on the Voltage display.
2.
Rotate the Voltage encoder 3 steps clockwise *.
LANG message appears on the Voltage display.
3.
Rotate the Current encoder to select the required language: GEN or SCPI **.
4.
Press the Current encoder to accept a parameter.
When the parameter is accepted, a display blinks once.
5.
To exit the menu, press the COMM button or the BACK button.
* If LAN interface is active, rotate the Voltage encoder 6 steps clockwise.
** If LAN or optional (i.e. IEEE, MODBUS TCP or EtherCAT) interface is active, only SCPI
language is available (for MODBUS TCP, registers are used. For EtherCAT, SDOs/PDOs are
used).
NOTE
NOTE
50
