5.11

Boolean Commands Return Value

Boolean Commands Return Value function provides the ability to select Boolean value reply type
for <Bool> parameter commands, between 0|1 to OFF|ON. For example, OUTPut[:STATe] <Bool>
default return value is 0|1, it could be switched to OFF|ON.
Refer to SYSTem[:COMMunicate]:BOOL[:STATe] <DSC> command in SCPI language, SYSTem
Subsystem, Section 4.14.10.
Refer to BOOL <DSC> command in GEN language, Auxiliary Commands, Section 4.10.8.
1. Only Return value is affected.
2. Boolean Commands Return Value function is available from firmware revision 02.110.
NOTES
153
