Display Text
PANEL
E.VOL
E.RES
C.SRC
RANGE
R.INT
C.PWR
POWER
SLEW
CSL.UP
CSL.DN
VSL.UP
VSL.DN
RESET
WD.TIM
1.8
Menu Navigation
1.8.1
Introduction
power supply series contains the following five independent menus:
•
COMMUNICATION
•
PROTECTION
•
CONFIGURATION
•
SYSTEM
•
PROGRAM
1.
To enter a menu, press COMM, PROT, CONF, SYST or PROG button. An appropriate LED
lights indicating that a menu is active.
2.
Navigate the menu by rotating the Voltage encoder to scroll through the selected Menu
functions.
3.
Rotate the Current Encoder to select a parameter or a parameter value.
4.
Press the Current Encoder to accept a desired parameter value.
5.
If the parameter is accepted, the display blinks once indicating the parameter is accepted.
Text Description
PANEL
EXTERNAL VOLTAGE
EXTERNAL RESISTANCE
CURRENT SOURCE
RANGE
INTERNAL RESISTANCE
CONSTANT POWER
POWER
SLEW
CURRENT SLEW UP
CURRENT SLEW DOWN
VOLTAGE SLEW UP
VOLTAGE SLEW DOWN
RESET
WATCHDOG TIMER
Table 1-6: Front Panel Display Messages
Display Text
Text Description
TRIG
TRIGGER
INIT
INIT
ABORT
ABORT
LOAD
LOAD
TRG.IN
TRIGGER INPUT
EXT
EXTERNAL
BUS
BUS
CONT
CONTINUES
TRG.DL
TRIGGER DELAY
TRG.OU
TRIGGER OUT
FSTR
FUNCTION STROBE
OPT
OPTIONAL COMMUNICATION
RES
RESISTANCE
WD
WATCHDOG
13
