6.2.4

Standard Event Status Group Structure

Standard event status group latches error groups. Power switch on and operation complete events
status might quickly change its condition before the controlling PC detects it. Events can be stored
in the ESB register if the Enable register allows it. Refer to Common Commands Group (section
4.13) for standard event status group commands. Table 6-3 describes bit configuration of the
standard event status register group. Standard event status group registers are cleared when read,
refer to *ESR? Command (section 4.13). To program specific bits in the standard event status
group enable register, refer to *ESE command (section 4.13). If *PSC is set, Enable register is
cleared at power supply power on.
Bit Number Decimal Value
0
1
2
3
4
5
6
7
Table 6-3: Bit Configuration of Standard Event Status Register
Operation Complete – Set whenever the last communication command completed its operation, the
unit is ready to accept another command.
QYE - Query commands related errors.
DDE – Device Dependent error codes.
EXE – Execution commands related errors.
CME – Commands errors.
Bit Set Error code
5 -100 ~ -199
4 -200 ~ -299
Bits 2, 3, 4 & 5 point to a specific group of errors. For a detailed errors list, refer to Table 6-5.
Power ON – Set once at power up.
Bit Symbol
1 OPC
2
4 QYE
8 DDE
16 EXE
32 CME
64
128 PON
Error Type Bit Set
Command 3
Execution 2
Table 6-4: Standard Event Status Register Error Bits
Description
Operation Complete
Query Error
Device Dependent Error
Execution Error
Command Error
Power ON
Error code
-300 ~ -399 or 1 ~ 32762
-400 ~ -499
NOTE
157
Error type
Device Dependent
Query
