5. LAN SETUP

5.1. View the IP and MAC Addresses

When the power supply is running with the LAN enabled, the IP and MAC addresses may be viewed on
the front panel by following these steps:
1. Press and hold the FOLD button for three seconds. The 7-segment displays will show something such as:
IP-1 010
By turning the voltage encoder knob, the complete IP and MAC addresses may be seen.
Note, all four numbers of the IP address may be changed through the web pages or from the front panel
(see next section). The MAC address cannot be changed.
Rotate voltage knob
2. If the voltage knob is not changed for five seconds, the supply will revert to the normal voltage and
current displays. If this happens, press and hold the FOLD button agai
IP-1 10
IP-2 225
IP-3 26
IP-4 38
AC-1 00
AC-2 19
AC-3 F9
AC-4 27
AC-5 d3
AC-6 b0
17
In this example,
the IP address is:
10.225.26.38
the MAC address is:
00:19:F9:27:D3:B0
( "AC" is short for "MAC")
