No.
Connection
11
Isolated control and
signals
12
Optional Interface
13
Service Port
* LAN Connector LEDs (Green & Amber) and Red Status Indicators might lit in Power Switch OFF
state.
Refer to the Safety & Installation Manual for any connect/disconnect of any connector on the rear
panel.
1.6
J1 Connector Terminal and Function
Control and monitoring signals are SELV.
Connector Technical Information:
Connector type: 618026325223, WURTH
DB26HD Receptacle type: 10090769-P264ALF, FCI
Wire: AWG 24-28
No.
Connection
1
Daisy In / SO
2
Daisy Out / PS_OK #2
3
PS_OK #1
4
CV/CC
Description
Isolated analog Control and monitoring signals, DB26HD type female,
isolated from the output potential.
Position for optional communication interface.
Service port for factory use. USB interface connector, type B. Connector
type: SAMTEC P/N: USBR-B-S-F-O-TH.
Table 1-4:
Rear Panel Connections and Controls
NOTE
WARNING
9
18
26
Figure 1–5: J1 Connector Terminals and Functions
Description
Input for Series Operation / Input for Shut Off control of the power supply
output.
Output for Series Operation / Output #2 for indication of power supply
status. High level is OK.
Output #1 for indication of power supply status. Open Collector type, low
level is OK.
Output for Constant-Voltage / Constant-Current mode indication.
1
10
19
10
