4.11

Serial Communication Test Set-Up

Basic set-up to test serial communication operation.
1 Equipment
2 PC Set-up
3 Power Supply Set-up
4 Communication
If USB communication is used, the USB driver installation is required prior communication.
PC with a serial communication terminal software installed, power
supply and RS232 or USB cable.
Bits per second: 115200
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
Connect power supply to the PC using RS232 or USB cable.
Set power supply settings:
Baud Rate – 115200
Address – 06
Interface – RS232 or USB
Communication Language – GEN
PC write: ADR 06
Power supply response: OK
PC write: OUT 1
Power supply should turn output ON.
Power supply response: OK
PC write: PV n (for n values, refer to
Power supply response: OK
PC write: PC m (for m values, refer to
Power supply response: OK
Display indicates the output voltage and actual output current.
If Blank Panel Power Supply is tested, add the following commands to
measure the output voltage and output current settings:
PC write: PV?
Power supply response: n (actual voltage setting)
PC write: PC?
Power supply response: m (actual current setting)
NOTE
95
Table 4-4
)
Table 4-5
)
