Task 14M: Check Hardware Status - Lucent Technologies DEFINITY AUDIX Installation And Upgrade

Initial System Administration

Task 14M: Check Hardware Status

This task is required for all installation scenarios.
1. With the cursor on the DEFINITY AUDIX command line, type
list configuration and press
The system displays the List Configuration screen.
2. Make sure the screen displays the following components (indicating that
the system correctly recognizes all the components).
3. If all the components are listed and shown in the proper location, skip to
Step 4. Otherwise, see DEFINITY AUDIX System — Maintenance ,
585-300-110, for troubleshooting procedures.
4. With the cursor on the DEFINITY AUDIX command line, type
status voice-group and press
3-28
Issue 2 December 1996
RETURN
ALARM_BD
ABP_FW
MFB_BD
FAC_FW
386_FW
DISK
TAPE
.
.
RETURN
