Task 9: Install the Printer (Optional)

6. Attach a 25-pair cable between the cross-connect field and the digital line
interface board (TN754) on the switch (labeled 6).
7. Attach a 25-pair cable between the cross-connect field and a second
digital line interface board (TN754) on the switch (labeled 7).
8. Attach a 3-pair cord from the cross-connect field to the 103A adapter
(labeled 8).
9. Attach one end of the D8W-87 modular cord to the 103A adapter (labeled
9).
10. Attach the other end of the D8W-87 (4-pair) modular cord to the modular
jack on the MPDM (labeled 10).
11. Attach one end of the Group 110 cable to the RS-232C connector of the
MPDM (labeled 11).
12. Attach the other end of the Group 110 cable to one of the four RS-232
connectors on the H600-347 (labeled 12).
13. Attach the other end of the H600-347 cable to an RS-232C connector on
the Packet Gateway board (TN577) on the G3r switch (labeled 13).
14. Proceed to Task 9: Install the Printer (Optional).
Task 9: Install the Printer (Optional)
This task is required only if the customer requested a printer on a DEFINITY
AUDIX system terminal.
This task describes how to install an Lucent 470 or 570 series printer. For other
printers follow the instructions supplied with the printer, making sure you set the
options required for the DEFINITY AUDIX system as described in this task.
1. Set up the printer.
a. Unpack and set up the printer according to the instructions
b. Be sure that the printer has paper, the ribbon is properly installed,
supplied with the printer.
and the cover is closed.
