Option Settings

CL Integration

Set the following MPDM options to the ON switch position if running CL
integration:
9600 (baud rate)
SYN
INT
AANS
Set all other options to OFF

7400A Data Module Settings

In the set interface option menu, set the ANS ONLY? option to YES. Then select
the following options:
Option
BAUD RATE
ANS
BRK DISK
CI
CH
CTS
DCD
DSR
DTR
DTR
LL
REMLOOP
RI
RL
SIGLS DISC
TM
DONE
See 7400A Data Module User's Manual , 555-020-706, for instructions on how set
options on the 7400A data module.
B-18
Issue 2 December 1996
Setting
1200 and 9600
AUTO
LONG
OFF
OFF
ON
NORMAL
ON
50 Msec
FOLLOW
OFF
GRANT
ON
OFF
OFF
OFF
YES
