Modem Option Settings
There are three jumper pins (labeled JP1 ) on the left side of the circuit board.
When the jumper plug connects the left and middle pins (as shown in the figure),
the modem is in the noncommand ( dumb ) mode. When the jumper plug
connects the right and middle pins, the modem is in the command mode (the
factory setting). To change the jumper setting, lift the plug up until it clears the
pins (the plug may have to be tilted outward to clear the top of the housing); then
slide the plug down on the middle pin and the other end pin. Replace the
endcap, reconnect the telephone wire and computer cable, and plug in the
power cord.
For more details on setting options for the Lucent 2400 modem, see the booklet
that is packaged with the modem.
Paradyne DataPort Express Modem
Option Settings
Connect the modem to a terminal (for example, the 715 BCT) with the terminal
speed set at 9600 bps. The maximum modulation data rate must be set to 9600 bps
when this modem is connected to DEFINITY AUDIX. Enter AT to get the OK prompt, then
enter the following string:
AT%B9600S2=128&W0
This command sets maximum rate to 9600, writes this setting to modem profile 0, and locks
out the escape character.
Paradyne COMSPHERE 3820 Modem
Option Settings
Change the following options from their defaults. Only the options that require
changing are listed — leave the defaults for all others.
Change Async DTE Rate to 9600 (default = 19200).
Change DTR Action To Stndrd_RS232 (default = ignore).
Paradyne COMSPHERE 3830 Modem
Option Settings
Connect the modem to a terminal (for example, the 715 BCT) with the terminal
speed set at 2400 bps. Enter AT to get the OK prompt; then enter the following
string to set the modem to noncommand (dumb) mode:
AT&D2Q1&W0
No other option settings are necessary.
