Hardware Upgrades

Hardware Upgrades
To upgrade any DEFINITY AUDIX to R3.2, the following items are necessary at
the upgrade site:
R3.2 generic software tape
Tape or tapes with purchased language sets
Two blank tapes, necessary to save customer data during the
upgrade. These tapes will not be left at the upgrade site.
TN566B MFB Circuit Card (upgrading R1.0 or R2.0 with support of 10
voice ports or less)
TN567 MFB Circuit Card (upgrading an R1.0 or R2.0 system and
additional voice ports are added; or upgrading an R3.0 or R3.1
system and 10 voice ports are needed)
TN2170 Alarm Board if adding I
Cabling for I
465 MB disk drive (for 40 hour of voice storage) optional
600 MB tape drive with a 1.05-GB disk drive (for 100 hours of voice
storage) optional . These must be installed as a set.
Control Link Cable (if changing to Control Link Emulation)
!
WARNING:
When upgrading to R3.2, the TN567 MFB should be installed during the
software upgrade. However, the system cannot return to a pre-R3.2
software state without removing the TN567 MFB and replacing it with
whatever was in the system before the upgrade started. The TN567 MFB
will be ruined if not removed.
NTUITY
Message Manager upgrade
NTUITY
NOTE:
Remember that all hardware and "R-type" tapes
removed during this upgrade must be returned to Lucent
Technologies.
Message Manager
Issue 2 December 1996
7-9
