Avaya Communication Server 1000M Series Upgrade page 56

Page 56 of 198 Performing the upgrade
Table 7
DC power requirements for Meridian 1 Option 51 upgrades
Order
number Description
NT6D41CA Core/Network Power Supply DC
NN43021-459 Standard 05.04
common equipment hardware only, including two CP PIV Pentium call
processor cards and two NTRB53 Clock Controller cards.
The NTHU44AA and DA packages contain common equipment hardware
only, including two CP PIV Pentium call processor cards and two NTRB53
Clock Controller cards.
These packages are designed for computer floor installation, with all cables
exiting from the pedestal. If the installation requires overhead cabling, order
NT7D0009 top egress panel, one per column.
An NT8D49AA Spacer kit is provided to allow for a side-by-side installation
of core/network modules. This arrangement requires an additional top cap
and pedestal package and must be ordered separately.
Intelligent peripheral equipment must be ordered separately. Order
NTWB15DA for any additional AC IPE Modules required.
Peripheral equipment (PE) or Enhanced peripheral equipment (EPE) is not
supported on systems with Pentium Processors.
Check required power equipment
Table 7 on page 56
Table 8 on page 57
WARNING
Ensure that power supplies NT6D41CA (DC) or
NT8D29BA (AC) are used in the Core/Net shelf.
March 2012
lists the equipment required for DC-powered systems.
lists the equipment required for AC-powered systems.
Quantity per
system
2
