Paper Feeder Removal - Lexmark CX825 Service Manual

6
Remove the four screws (A), and then remove the cover.

Paper feeder removal

1
Remove the pick roller. See
2
Press and hold the latch (A), and then rotate and remove the paper stopper (B).
3
Lower the latch (C) to release, and then remove the feeder bearing (D).
Note: The shaft may need to be slightly rotated to align it with the hole on the feeder bearing.
"Pick roller removal" on page
A
Repair information
665
A
654.
B
7564
