Staple finisher exit gears removal
1
Remove the front cover. See
2
Disconnect the three cables (A), and then remove the four screws (B).
3
Set aside the aligner paddle motor and bracket.
4
Remove the front upper position exit roller gears. See
removal" on page 819.
"Staple finisher front cover removal" on page
B
Repair information
A
"Staple finisher front upper position exit roller gears
817
787.
7564
