Applicator and Sensor Pod

What it is called What it does
Applicator
Applicator Barrel
Safety Lock
Collar
Plunger
Transmitter Latch
Sensor Pod
Sensor Pod
Adhesive Patch
Sensor Wire
Dexcom G5 Mobile System User Guide
What is the Dexcom G5 Mobile CGM System?
Contains small insertion needle and sensor wire.
Inserts sensor wire under the skin.
Disposable, for single use only.
Removed after insertion.
Keeps all moving parts in place before insertion.
Prevents accidental sensor insertion.
Tool to remove transmitter after sensor session.
Put in transmitter box after removal to use later.
Collar removes insertion needle.
Inserts sensor wire into your body.
Securely snaps transmitter into sensor pod.
Holds transmitter and sensor wire.
Water resistant when transmitter is properly installed.
Discarded after sensor session.
Keeps sensor pod attached to your skin.
Wire measures glucose levels in fluid in between your cells.
Attached to sensor pod.
Discarded with pod after session.
