Factory Five Racing Mk4 Roadster Assembly Manual page 507

11070 WIRING HARNESS MOUNTING HARDWARE
10984 BOLT, #14 x 1/2"
13979 SCREW WITH COUNTERSUNK WASHER, #8 x 3/4"
10995 SCREW, #10 X 1" , (INERTIA CUT-OFF SWITCH)
10851 SCREW, #14 x 1 1/2", (VACUUM CONTROLS)
11217 RING CONNECTOR, 16 GAUGE, BLUE, (COMPUTER GROUND)
13647 FUSE PANEL MOUNT, ALUMINUM
13327 DASH ELECTRICAL COMPONENTS
10995 SCREW, SELF TAPPING #10
14824 WIRE EXTENSION, 16 GAUGE, BLUE
11180 FEMALE BLADE CONNECTOR, BLUE, ¼"
10817 BLUE LIGHT, (HIGH BEAM INDICATOR)
10816 GREEN LIGHT, (TURN SIGNAL INDICATOR)
10815 RED LIGHT, (WARNING INDICATOR)
10596 ON/OFF SWITCH
13979 SCREW W/COUNTERSUNK WASHER, #8 x 3/4"
11288 FLASHER, 3 PRONG
11053 HORN BUTTON
14744 ASTON LEMANS CAP COMPONENTS
14651 ASTON LEMANS CAP
INCLUDED WITH ABOVE PART#
LEMANS ALUMINUM CAP
LEMANS CAP TO BODY GASKET
2 HOSE CLAMP, 1 9/16" – 2 ½"
5 #8 x 3/4" SCREW
GROUND STRAP
#8-32, 1" BOLT
#8-32 LOCKNUT
WASHER
#14 x ½" SCREW
11030 EXTENSION TUBING, RUBBER 2" ID
14617 PLASTIC FILL CAP
14652 FUEL LINE COMPONENTS
14745 UNION, ¼"
14844 BARB, ¼"
14747 UNION, 5/16"
14748 BARB, 5/16"
10855 HOSE CLAMP, 1/4" FUEL LINE
11138 HOSE CLAMP, 5/16" FUEL LINE
13900 FLEXIBLE FUEL LINE, 1/4" ID, HIGH PRESSURE
13932 FLEXIBLE FUEL LINE, 5/16" ID, HIGH PRESSURE
10984 SCREW, #14 x 1/2", (FUEL FILTER MOUNTING)
11076 BRAKE LINE COMPONENTS
11024 BOLT, 5/16"-18 x 1", (EMERGENCY BRAKE HANDLE)
13025 "U" NUT, 5/16"-18, (EMERGENCY BRAKE HANDLE)
11005 WASHER, 5/16" USS, (EMERGENCY BRAKE HANDLE)
10984 SCREW, #14 x 1/2", (DONOR BRAKE LINE BRACKET)
13653 BRAKE LINE MOUNT BRACKET, 1/8" STEEL
12962 SCREW, #6x 1/2", (BRAKE LINE MOUNT BRACKET)
13743 BRAKE LINE UNION, 3/16"
25507 BRAKE LINE "T" ADAPTER, 2 FEMALE, 1 MALE
25502 10MM BRAKE LINE METRIC ADAPTER
12409 ¼" BRAKE LINE ADAPTER
END OF BOX 2A
506
www.factoryfive.com 508-291-3443
EA 7.00
EA 8.00
EA 2.00
EA 2.00
EA 1.00
EA 1.00
EA 4.00
FT 4.00
EA 4.00
EA 1.00
EA 1.00
EA 1.00
EA 2.00
EA 12.00
EA 1.00
EA 1.00
EA 1.00
FT 1.00
EA 1.00
EA 1.00
EA 2.00
EA 1.00
EA 2.00
EA 5.00
EA 5.00
FT 3.00
FT 3.00
EA 3.00
EA 2.00
EA 2.00
EA 2.00
EA 3.00
EA 2.00
EA 4.00
EA 2.00
EA 1.00
EA 1.00
EA 1.00
