Factory Five Racing Mk4 Roadster Assembly Manual page 511
Complete kit
Hide thumbs
Also See for Mk4 Roadster:
- Assembly manual (546 pages) ,
- Assembly manual (551 pages) ,
- Assembly manual (523 pages)
Table of Contents
Advertisement
FFR #
Part Name
10789
AIR FILTER, CONICAL
10781
FAN BELT, SIX RIB, SINGLE
13661
A-FRAME TRANSMISSION MOUNT /HARDWARE
13929
TRANSMISSION BOLT ON MOUNT, A-FRAME, POWDER COATED
10833
BOLT, 1/2"x 1.25"
10834
LOCK NUT, NYLON, 1/2"-13
10520
BOLT, 3/8"x 1.00"
13964
LOCK NUT, NYLON, 3/8"-16
11080
ALTERNATE DRIVE PULLEY COMPONENTS
10775
PULLEY WHEEL, (TO REPLACE A/C)
10952
PULLEY SPACER, MACHINED ALUMINUM
12386
BOLT, ½"-13 x 3.25"
10834
LOCKNUT, NYLON, ½"-13
13976
WASHER, ½" SAE
13777
ACCELERATOR CABLE COMPONENTS
13774
ACCELERATOR PEDAL CAPTURE
13775
ACCELERATOR CABLE
11212
5/16-24 LOCK NUT
13974
RETURN SPRING
13975
BALL STUD RETAINER W/BALL STUD
10992
OIL FILTER RELOCATING KIT
12119
OIL FILTER RELOCATOR, (BOLTS ON TO CHASSIS)
10995
SCREW, #10 X 1", OIL FILTER RELOCATOR SCREW
10635
WASHER, #10, OIL FILTER RELOCATOR WASHER
12132
THREADED NIPPLE, (SCREWS INTO RELOCATOR)
12120
SPIN-ON-ADAPTER, (SCREWS ONTO ENGINE BLOCK)
12133
O-RING
12121
BRASS FITTING, BARBED, 1/2"x1/2" MPT
12134
THREADED HOLE PLUG
12118
OIL HOSE, 1/2"ID x 5FT
11206
HOSE CLAMP, (CONNECTION FROM HOSE TO BARBS)
13883
STAINLESS RADIATOR HOSE KIT
13392
CORRUGATED METAL HOSE
13930
RADIATOR HOSE ADAPTER SET W/CLAMPS
INCLUDED WITH ABOVE PART#
REINFORCED 2.5" LONG RUBBER HOSE
SMALL RUBBER HOSE ADAPTER
LARGE RUBBER HOSE ADAPTER
2 HOSE CLAMPS
10760
FAN MOUNTING COMPONENTS
10668
RADIATOR FAN, 16", REVERSIBLE, 1620 CFM @ 13.7 A
10954
FAN MOUNT BAR, 1/16" STEEL
13979
SCREW WITH COUNTERSUNK WASHER, #8 x 3/4"
12455
FAN RELAY, SPST, 30/40 AMP
25839
RELAY SOCKET
10942
WIRE EXTENSION, 16 GAUGE, (FOR FAN WIRING)
10941
BUTT CONNECTORS, BLUE
11217
RING CONNECTORS, BLUE, 16 GAUGE, (FAN GROUND)
11180
0.25" FEMALE BLADE CONNECTOR
10984
SCREW, #14 x 1/2", (GROUND)
BOX 4A ANCILLARY COMPONENTS
END OF BOX 4A
