How to use This Book

This Assembly manual is intended to help you build your Factory Five Kit. This book will not explain
such things as engine or transmission building. A secondary purpose of this book is to use it as
reference for owners that want to do maintenance work on their cars or for those that purchase finished
cars, to understand their cars better.
This manual was written with the average weekend mechanic in mind. It is best to follow the manual
step by step but if there is a part missing from the kit move to the next section and come back to it late
when the part is available. If the instructions are followed then the resulting car should be a great
handling sports car.
I C O N K E Y
Valuable information
Tools needed
Parts Needed

What You Get

The Factory Five Mk IV Roadster kit gives you everything you need to build your car, in one big
package. We include everything from the frame, body, complete interior, and all trim down to the
smallest details like correct fasteners, brackets, and badges. We make it easy for you to use the engine
of your choice with a list of available exhaust and motor/trans mount choices (no charge). For a
complete packing list, see the Appendix.
Frame: Complete jig-welded Powder coated tube frame. Includes all mounts ready to accept all
Ford Engines: Small block, 4.6L, 427/428 FE, 429/460 engines.
Body: Hand laid /
3
Chassis Aluminum Panels: 66 Laser cut, pre-formed 6061-T6 aluminum panels for cockpit, trunk,
and engine bay. 1200 pre-packaged rivets.
Complete Front Suspension: Tubular upper and lower control arms, Koni
performance mono-tube, rod-end shock absorbers, Custom Spindles, Hubs.
Rear Suspension: 3-Link Suspension, tubular lower control arms, Koni
mono-tube, rod-end shock absorbers.
Front Brake System: Ford Mustang GT 11" front brakes including twin piston PBR
calipers, brake pads, stainless braided brake lines, fasteners, pre-flared
emergency brake handle.
Complete Steering System: Manual steering rack, polyurethane bushings, nickel plated lower
steering shaft, 14" wood steering wheel w/boss and ceramic Factory Five Badge.
Fuel System/Parts: Fuel tank w/mounting hardware, vent, gaskets, pick-up and fuel level sending
unit, fuel filler neck and fasteners, pre-flared fuel lines (¼" and
clamps and high press flex lines, polished Aston Lemans aluminum fuel cap with gasket,
ground strap.
We have included an Icon key as the beginning of each section that contains
useful information for each assembly that details the tools needed for that
assembly, what assembly in the kit parts are packaged in that are needed for that
step and any useful information or warnings.
" laminate composite body and panels made with vinyl ester resin.
