TABLE 4-2
PCIe Bus
A
B
* Data Rate shown is per lane and per direction.
** Internal SAS Controller Card Expansion Connector not in use at time of this release
*** Slot Consumed by the SAS1068 Disk Controller
FIGURE 4-4
82 Sun Fire V445 Server Administration Guide • September 2007
PCI Bus Characteristics, Associated Bridge Chips, Motherboard Devices,
and PCI Slots
Data Rate /
Bandwidth Integrated Devices
2.5 Gb/sec * Gigabit Ethernet 0
8 lanes
Gigabit Ethernet 1
PCI-X Bridge 0
2.5Gb/sec * PCI-X Bridge 1
8 lanes Gigabit Ethernet 2
Gigabit Ethernet 3
Southbridge M1575
(USB 2.0 Controller
DVD-ROM Controller
Miscelaneous System
Devices)
shows the PCI card slots on the motherboard.
PCI Slot Type / Number / Capability
PCIe Slot 0 x16 (wired x8)
PCIe Slot 6 x8 (wired x16)
SAS Controller Expansion Connector
**
PCI-X Slot 2 64-bit 133MHz 3.3v
PCI-X Slot 3 64-bit 133MHz 3.3v
PCI-X Slot 4 64-bit 133MHz 3.3v ***
PCI-X Slot 5 64-bit 133MHz 3.3v
PCIe Slot 1 x16 (wired x8)
PCIe Slot 7 x8 (wired x16)
