A
A P P E N D I X

Connector Pinouts

This appendix provides reference information about the system back panel ports and
pin assignments.
Topics covered in this appendix include:
"Reference for the Serial Management Port Connector" on page 235
"Reference for the Network Management Port Connector" on page 236
"Reference for the Serial Port Connector" on page 238
"Reference for the USB Connectors" on page 239
"Reference for the Gigabit Ethernet Connectors" on page 240
Reference for the Serial Management
Port Connector
The serial management connector (labeled SERIAL MGT) is an RJ-45 connector
located on the back panel. This port is the default connection to the system console.
