Reference For System Console Openboot Configuration Variable Settings - Sun Microsystems Sun Fire V445 Server Administration Manual

Reference for System Console OpenBoot
Configuration Variable Settings
The Sun Fire V445 system console is directed to the serial management and network
management ports (SERIAL MGT and NET MGT) by default. However, you can
redirect the system console to the serial DB-9 port (TTYB), or to a local graphics
monitor, keyboard, and mouse. You can also redirect the system console back to the
serial management and network management ports.
Certain OpenBoot configuration variables control from where system console input
is taken and to where its output is directed. The table below shows how to set these
variables in order to use the serial management and network management ports,
TTYB, or a local graphics monitor as the system console connection.
OpenBoot Configuration Variables That Affect the System Console
TABLE 2-20
OpenBoot Configuration Variable
Name
output-device
input-device
* POST output will still be directed to the serial management port, as POST has no mechanism to direct its output
to a graphics monitor.
The serial management port and network management port are present in the
OpenBoot configuration variables as ttya. However, the serial management port
does not function as a standard serial connection. If you want to connect a
conventional serial device (such as a printer) to the system, you need to connect it to
TTYB, not the serial management port. See
more information.
The sc> prompt and POST messages are only available through the serial
management port and network management port. In addition, the ALOM system
controller console command is ineffective when the system console is redirected to
TTYB or a local graphics monitor.
In addition to the OpenBoot configuration variables described in
are other variables that affect and determine system behavior. These variables are
created during system configuration and stored on a ROM chip.
System Console Output
Serial and
Network
Management Ports Serial Port (TTYB)
ttya ttyb
ttya ttyb
"About the Serial Ports" on page 96
Chapter 2 Configuring the System Console
Local Graphics
*
*
Monitor
screen
keyboard
for
, there
TABLE 2-20
59
