PCI0
PCI6
PCI7
PCI1
PCI3
PCI5
PCI4
PCI2
PCI Slot Locations
FIGURE 1-8
For more information about how to install a PCI card, see the Sun Fire V445 Server
Service Manual.
For more information about PCI cards, see
"About the PCI Cards and Buses" on
page
81.
18
Sun Fire V445 Server Administration Guide • September 2007
