Page 47: Sun Fire V490 Server Installation
This chapter provides both an overview of, and instructions for, the hardware and software tasks you need to accomplish to get the Sun Fire V490 server up and running. This chapter explains some of what you need to do, and points you to the appropriate section in this guide, or to other manuals for more information.
Page 48: How To Install The Sun Fire V490 Server
Each step in this procedure refers you to a particular document or to a section of this guide for instructions. Complete each step in the order listed. The best way to begin your installation of a Sun Fire V490 server is by completing the rackmounting and setup procedures in the Sun Fire V490 Server Setup and Rackmounting Guide.
Page 49: What To Do
Once you have answered these questions, you are ready to begin the installation. What to Do If you have completed the procedures in the Sun Fire V490 Server Setup and Rackmounting Guide, begin this procedure at Step 7. 1. Verify that you have received all the parts of your system.
Page 50 4. Install any optional components shipped with your system. If you ordered options that are not factory-installed, refer to the Sun Fire V490 Server Parts Installation and Removal Guide for installation instructions. Note – Do not attempt to access any internal components unless you are a qualified service technician.
Page 51 160. 12. (Optional) Install a local graphics terminal. After you have installed the Sun Fire V490 system and the Solaris OS, if you prefer to use a graphics terminal as your system console, you can install a graphics card and attach a monitor, mouse, and keyboard to the server. Refer to “How to...
Page 52 Sun Fire V490 Server Administration Guide • October 2005...
Page 53 Background PA RT The five chapters within this part of the Sun Fire V490 Server Administration Guide explain and illustrate in detail the various components of the server’s hardware, software, and firmware. Use the chapters as a guided tour through the panels, cables, cards, switches, and so forth that make up your server.
Page 55: System Overview
C H A P T E R System Overview This chapter introduces you to the Sun Fire V490 server and describes some of its features. The following information is covered in this chapter: “About the Sun Fire V490 Server” on page 9 ■...
Page 56 Sun Fire V490/V890 CPU/Memory Module Configuration Guide, available at: http://www.sun.com/products-n-solutions/hardware/docs/Servers A fully configured Sun Fire V490 system includes a total of four processors residing on two CPU/Memory boards. For more information, refer to “About the CPU/Memory Boards”...
Page 57 “How to Configure Additional Network Interfaces” on page 146. The Sun Fire V490 server provides a serial communication port, which you can access through an RJ-45 connector located on the system’s back panel. For more information, refer to “About the Serial Port” on page...
Page 58: Locating Front Panel Features
However, even if the top panel lock is in the Locked position, thereby locking both the PCI and CPU access panels, you can still unlock the media door security lock and Sun Fire V490 Server Administration Guide • October 2005...
Page 59: Led Status Indicators
gain access to the disk drives, power supplies, and Fan Tray 0. If the media door is locked and the power supply access panel is in place, you will not be able to gain access to the power supplies, disk drives, and Fan Tray 0—even if the PCI access panel is unlocked.
Page 60: Table 2-1 System Leds
Further details about the diagnostic use of LEDs are discussed separately in the section, “How to Isolate Faults Using LEDs” on page 172. Sun Fire V490 Server Administration Guide • October 2005...
Page 61: Power Button
Power Button The system Power button is recessed to prevent accidentally turning the system on or off. The ability of the Power button to turn the system on or off is controlled by the system control switch. Refer to the section, “System Control Switch”...
Page 62: Locating Back Panel Features
However, the system controller card continues to operate using the system’s 5-volt standby power. Locating Back Panel Features The following figure shows the system features that you can access from the back panel. Sun Fire V490 Server Administration Guide • October 2005...
Page 63: Figure 2-3 Sun Fire V490 Server Back Panel Features
AC input for Power Supply 1 refer to Figure 2-4.) Power Supply 1 status LEDs Sun Fire V490 Server Back Panel Features FIGURE 2-3 Main system LEDs—Locator, Fault, and Power/OK—are repeated on the back panel. (Refer to , and for descriptions of front panel LEDs.) In...
Page 64: Figure 2-4 Back Panel External Ports
One system controller (SC) card slot ■ Six external data ports: USB, serial, Ethernet, and FC-AL (refer to ■ FIGURE 2-4 USB ports (2) Ethernet ports Serial port FC-AL port Back Panel External Ports FIGURE 2-4 Sun Fire V490 Server Administration Guide • October 2005...
Page 65: About Reliability, Availability, And Serviceability Features
Together, reliability, availability, and serviceability features provide for near continuous system operation. To deliver high levels of reliability, availability and serviceability, the Sun Fire V490 system offers the following features: Hot-pluggable disk drives ■...
Page 66: Power Supply Redundancy
AC power source fail. For more information about power supplies, redundancy, and configuration rules, refer to “About the Power Supplies” on page Environmental Monitoring and Control The Sun Fire V490 system features an environmental monitoring subsystem designed to protect against: Extreme temperatures ■...
Page 67: Automatic System Recovery
The implementation of ASR on the Sun Fire V490 server is different. ASR on the Sun Fire V490 server provides for automatic fault isolation and...
Page 68: Sun Remote System Control Software
The RSC software works with the system controller (SC) card on the Sun Fire V490 system PCI riser board. The SC card provides an Ethernet connection to a remote console and a serial connection to a local alphanumeric terminal.
Page 69: Hardware Watchdog Mechanism And Xir
Hardware Watchdog Mechanism and XIR To detect and respond to system hang conditions, the Sun Fire V490 system features a hardware watchdog mechanism—a hardware timer that is continually reset as long as the operating system is running. In the event of a system hang, the operating system is no longer able to reset the timer.
Page 70: Support For Raid Storage Configurations
Support for RAID Storage Configurations By attaching one or more external storage devices to the Sun Fire V490 server, you can use a software RAID application, such as Sun StorEdge™, to configure system disk storage in a variety of different RAID levels. Configuration options include RAID 0 (striping), RAID 1 (mirroring), RAID 0+1 (striping plus mirroring), RAID 1+0 (mirroring plus striping), and RAID 5 (striping with interleaved parity).
Page 71: Hardware Configuration
C H A P T E R Hardware Configuration This chapter provides hardware configuration information for the Sun Fire V490 server. The following topics are covered in this chapter: “About Hot-Pluggable and Hot-Swappable Components” on page 26 ■ “About the CPU/Memory Boards” on page 27 ■...
Page 72: About Hot-Pluggable And Hot-Swappable Components
About Hot-Pluggable and Hot- Swappable Components In a Sun Fire V490 system, the FC-AL disk drives are hot-pluggable components and the power supplies are hot-swappable. (No other component of the system is either hot-pluggable or hot-swappable.) Hot-pluggable components are those that you can install or remove while the system is running, without affecting the rest of the system’s capabilities.
Page 73: Disk Drives
Sun Fire V490 internal disk drives are hot-pluggable. However, certain software preparations are required prior to removing or installing a drive. To perform Sun Fire V490 disk drive hot-plug operations, you use the Solaris luxadm utility. The luxadm utility is a command-line tool for managing intelligent storage arrays such as Sun StorEdge A5x00 series disk arrays or Sun Fire V490 internal storage arrays.
Page 74: About The Memory Modules
DIMM slots FIGURE 3-1 and DIMM groups on a Sun Fire V490 CPU/Memory board. Every fourth slot belongs to the same DIMM group. The four groups are designated A0, A1, B0, and Sun Fire V490 Server Administration Guide • October 2005...
Page 75: Figure 3-1 Memory Module Groups A0, A1, B0, B1
Memory Module Groups A0, A1, B0, B1 FIGURE 3-1 You must physically remove a CPU/Memory board from the system before you can install or remove DIMMs. The DIMMs must be added four-at-a-time within the same DIMM group, and each group used must have four identical DIMMs installed—that is, all four DIMMs in the group must be from the same manufacturing vendor and must have the same capacity (for example, four 512-Mbyte DIMMs or four 1-Gbyte DIMMs).
Page 76: Memory Interleaving
One processor controls DIMM groups A0 and A1, while the other processor controls DIMM groups B0 and B1. The Sun Fire V490 system uses a shared memory architecture. During normal system operations, the total system memory is shared by all processors in the system.
Page 77: Configuration Rules
Note – Do not attempt to access any internal components unless you are a qualified service technician. Detailed service instructions can be found in the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD.
Page 78: Figure 3-2 Pci Slots
Note – PCI cards in a Sun Fire V490 system are not hot-pluggable. PCI Bus Characteristics, Associated Bridge Chips, Centerplane Devices, TABLE 3-2 and PCI Slots Clock Rate (MHz)/ Bandwidth (bits)/ PCI Bridge PCI Bus Voltage (V) Integrated Devices PCI Slots...
Page 79: Configuration Rules
About the System Controller (SC) Card The system controller (SC) card enables access, monitoring, and control of the Sun Fire V490 server from a remote location. It is a fully independent processor card with its own resident firmware, power-on self-test (POST) diagnostics, and real-time operating system.
Page 80: Figure 3-4 Sc Card Ports
The SC card features serial and Ethernet interfaces that provide simultaneous access to the Sun Fire V490 server for multiple RSC software users. RSC software users are provided secure access to the system’s Solaris and OpenBoot console functions and have full control over power-on self-test (POST) and OpenBoot Diagnostics.
Page 81: Configuration Rules
Documentation CD. About Hardware Jumpers Three jumpers are located on the Sun Fire V490 system’s PCI riser board. Note that jumpers are set at the factory to ensure best system performance. Be aware that moving any jumper shunt from its default location can render the system unstable or unusable.
Page 82: Pci Riser Board Jumpers
1 + 2 populating connector in J1102 position J1101 Reserved for future use Reserved for future use 1 + 2 J1103 OpenBoot flash PROM OpenBoot flash PROM 1 + 2 Write-enabled Write-protected J1104 Sun Fire V490 Server Administration Guide • October 2005...
Page 83: About The Power Supplies
PDB by way of two board-mounted IEC320 receptacles, each dedicated to one power supply. The Sun Fire V490 system’s N+1 redundant power supplies are modular units, designed for fast, easy installation or removal, even while the system is fully operational.
Page 84: Configuration Rule
Good practice is to connect each power supply to a separate AC circuit, which ■ will maintain N+1 redundancy and enable the system to remain operational if one of the AC circuits fails. Consult your local electrical codes for any additional requirements. Sun Fire V490 Server Administration Guide • October 2005...
Page 85: About The Fan Trays
PCI access panel to gain access to it. Power supplies are cooled separately, each with its own internal fans. Caution – Fans on a Sun Fire V490 system are not hot-pluggable. Do not attempt to access any internal components unless you are a qualified service technician.
Page 86: Configuration Rule
Note – Do not attempt to access any internal components unless you are a qualified service technician. Detailed service instructions can be found in the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD.
Page 87: About Fc-Al Technology
About FC-AL Technology Fibre Channel (FC) is a high-performance serial interconnect standard designed for bidirectional, point-to-point communication among servers, storage systems, workstations, switches, and hubs. Fibre Channel-Arbitrated Loop (FC-AL) is an important enhancement to the FC standard, developed specifically to meet the needs of storage system interconnects. Employing a simple loop topology, FC-AL can support both simple configurations and complex arrangements of hubs, switches, servers, and storage systems.
Page 88: About The Fc-Al Backplane
* The 127 supported devices include the FC-AL controller required to support each arbitrated loop. About the FC-AL Backplane All Sun Fire V490 servers include a single FC-AL backplane with connections for two internal hard disks, both of which are hot-pluggable.
Page 89: Configuration Rules
■ For information about installing or removing an FC-AL disk or disk backplane, refer to the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD. About the HSSDC FC-AL Port The Sun Fire V490 system back panel includes an FC-AL port with a high-speed serial data connector (HSSDC).
Page 90: Configuration Rules
(Loop B). For this purpose, Sun offers the Sun StorEdge PCI Dual Fibre Channel Host Adapter card. Refer to the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD, for installation instructions.
Page 91: Configuration Rule
For your convenience, a serial port adapter (part number 530-2889-03) is included in your Sun Fire V490 server ship kit. This adapter enables you to use a standard RJ-45 serial cable to connect directly from the serial connector on the back panel to a Sun workstation, or to any other terminal that is equipped with a DB-25 serial connector.
Page 92 However, you can only perform USB hot-plug operations while the operating system is running. USB hot-plug operations are not supported when the system ok prompt is displayed. Sun Fire V490 Server Administration Guide • October 2005...
Page 93: Network Interfaces And System Firmware
“Reference for Device Identifiers” on page 61 ■ About the Network Interfaces The Sun Fire V490 server provides two on-board Ethernet interfaces, which reside on the system centerplane and conform to the IEEE 802.3z Ethernet standard. For an illustration of the Ethernet ports, refer to .
Page 94: About Redundant Network Interfaces
64. You can also install a pair of identical PCI network interface cards, or add a single card that provides an interface identical to one of the two on-board Ethernet interfaces. Sun Fire V490 Server Administration Guide • October 2005...
Page 95: About The Ok Prompt
A synopsis of run levels follows; for a full description, refer to the Solaris system administration documentation. Most of the time, you operate a Sun Fire V490 system at run level 2, or run level 3, which are multiuser states with access to full system and network resources.
Page 96: What You Should Know About Accessing The Ok Prompt
Prompt It is important to understand that when you access the ok prompt from a functioning Sun Fire V490 system, you are suspending the Solaris OS software and placing the system under firmware control. Any processes that were running under the Solaris OS software are also suspended, and the state of such processes may not be recoverable.
Page 97: Stop-A (L1-A) Or Break Key Sequence
When it is impossible or impractical to halt the system gracefully, you can get to the ok prompt by typing the Stop-A (or L1-A) key sequence from a Sun keyboard, or, if you have an alphanumeric terminal attached to the Sun Fire V490 system, by pressing the Break key.
Page 98: About Openboot Environmental Monitoring
About OpenBoot Environmental Monitoring Environmental monitoring and control capabilities for Sun Fire V490 systems reside at both the operating system level and the OpenBoot firmware level. This ensures that monitoring capabilities are operational even if the system has halted or is unable to boot.
Page 99: Automatic System Shutdown
Note – Using the Stop-A keyboard command to enter the OpenBoot environment during power-on or reset will immediately disable the OpenBoot environmental monitor. If you want the OpenBoot PROM environmental monitor enabled, you must re-enable it prior to rebooting the system. If you enter the OpenBoot environment through any other means—by halting the operating system, by power- cycling the system, or as a result of a system panic—the OpenBoot environmental monitor will remain enabled.
Page 100: About Openboot Emergency Procedures
(indicated by the display of the ok prompt). The key sequence works the same on the Sun Fire V490 server as it does on older systems with non-USB keyboards, except that it does not work during the first few seconds after the machine is reset.
Page 101: Stop-F Functionality
“How to Implement Stop-N Functionality” on page 164. The drawback of using Stop-N on a Sun Fire V490 system is that, if diagnostics are enabled, it can take some time for the system to reach the desired state. Fortunately, an alternative exists: Place the system control switch in the Diagnostics position.
Page 102: Auto-Boot Options
The OpenBoot firmware then deconfigures the failed device and reboots the operating system. This all occurs automatically, as long as the Sun Fire V490 system is capable of functioning without the failed component. Once restored, the operating system will not attempt to access any deconfigured device.
Page 103: Error Handling Summary
Error Handling Summary Error handling during the power-on sequence falls into one of three cases summarized in the following table. Scenario System Behavior Notes No errors are The system attempts to boot if By default, auto-boot? and auto-boot-on- detected. auto-boot? is true. error? are both true.
Page 104: Reset Scenarios
(reboot, shutdown, init). Any kind of system reset. all-resets Diagnostic tests are not executed. none Refer to for a fuller list of OpenBoot configuration variables affecting TABLE 6-2 diagnostics and system behavior. Sun Fire V490 Server Administration Guide • October 2005...
Page 105: Normal Mode And Service Mode Information
OpenBoot configuration variables that affect ASR behavior, in OpenBoot PROM Enhancements for Diagnostic Operation, which is available on the Sun Fire V490 Documentation CD. About Manually Configuring Devices This section explains the difference between deconfiguring a device and a slot, tells what happens if you try to deconfigure all of a system’s processors, and also...
Page 106: Device Paths
“How to Deconfigure a Device Manually” on page 162 ■ “How to Reconfigure a Device Manually” on page 163 ■ Device identifiers are listed in “Reference for Device Identifiers” on page Sun Fire V490 Server Administration Guide • October 2005...
Page 107: Reference For Device Identifiers
Reference for Device Identifiers Refer to the following table when manually specifying which devices to deconfigure and reconfigure. The related procedures are covered in: “How to Deconfigure a Device Manually” on page 162 ■ “How to Reconfigure a Device Manually” on page 163 ■...
Page 108 Sun Fire V490 Server Administration Guide • October 2005...
Page 109: System Administration Software
C H A P T E R System Administration Software This chapter provides an introduction to system administration software tools supported on the Sun Fire V490 system. The following information is covered in this chapter: “About System Administration Software” on page 63 ■...
Page 110: About Multipathing Software
FC-AL host bus adapters connected to the same dual-ported storage array. For Sun Fire V490 systems, three different types of multipathing software are available: Solaris IP Network Multipathing software provides multipathing and load ■...
Page 111: For More Information
For instructions on how to configure and administer Solaris IP Network Multipathing, consult the IP Network Multipathing Administration Guide provided with your specific Solaris release. For more information about Sun StorEdge Traffic Manager, refer to the Sun Fire V490 Server Product Notes. For information about MPxIO, refer to “Multiplexed I/O (MPxIO)”...
Page 112: Multiplexed I/O (Mpxio)
Multiplexed I/O (MPxIO) A newer alternative to dynamic multipathing (DMP) that is also supported by the Sun Fire V490 server is multiplexed I/O (MPxIO). Beginning with Solaris 8, MPxIO is fully integrated within the Solaris OS software’s core I/O framework. MPxIO enables you more effectively to represent and manage devices that are accessible through multiple I/O controller interfaces within a single instance of the Solaris OS.
Page 113: Disk Concatenation
Disk Concatenation Disk concatenation is a method for increasing logical volume size beyond the capacity of one disk drive by creating one large volume from two or more smaller drives. This lets you create arbitrarily large partitions. Using this method, the concatenated disks are filled with data sequentially, with the second disk being written to when no space remains on the first, the third when no room remains on the second, and so on.
Page 114: Raid 5: Disk Striping With Parity
For More Information Refer to the documentation supplied with Solstice DiskSuite software. For more information about MPxIO, refer to your Solaris system administration documentation. Sun Fire V490 Server Administration Guide • October 2005...
Page 115: About Sun Cluster Software
About Sun Cluster Software Sun™ Cluster software lets you connect up to eight Sun servers in a cluster configuration. A cluster is a group of nodes that are interconnected to work as a single, highly available and scalable system. A node is a single instance of Solaris software—it may be running on a standalone server or on a domain within a standalone server.
Page 116: What The System Console Does
During initial installation of the Sun Fire V490 system and the Solaris OS software, you must use the built-in serial port (ttya) to access the system console. After installation, you can configure the system console to use different input and output devices.
Page 117: Default System Console Configuration
Using a Local Graphics Terminal as the System Console The Sun Fire V490 server is shipped without a mouse, keyboard, monitor, or frame buffer for the display of graphics. To install a local graphics terminal on the server, you must install a graphics frame buffer card into a PCI slot, and attach a monitor, mouse, and keyboard to the appropriate back panel ports.
Page 118 “How to Redirect the System Console to the System Controller” on page 160. For instructions on configuring and using RSC software, refer to the Sun Remote System Control (RSC) 2.2 User’s Guide. Sun Fire V490 Server Administration Guide • October 2005...
Page 119: Diagnostic Tools
12). About the Diagnostic Tools Sun provides a wide spectrum of diagnostic tools for use with the Sun Fire V490 server. These tools range from the formal—like Sun’s comprehensive Validation Test Suite (SunVTS), to the informal—like log files that may contain clues helpful in...
Page 120: Table 6-1 Summary Of Diagnostic Tools
SunVTS Software Exercises and stresses the system, Requires operating system. View and running tests in parallel Optional package may control over need to be installed network Sun Fire V490 Server Administration Guide • October 2005...
Page 121 There are a number of reasons for the lack of a single all-in-one diagnostic test, starting with the complexity of the server systems. Consider the data bus built into every Sun Fire V490 server. This bus features a five- way switch called a CDX that interconnects all processors and high-speed I/O interfaces (refer to ).
Page 122: Figure 6-1 Simplified Schematic View Of A Sun Fire V490 System
IDPROM HSSDC, USB, & Ethernet I/O C Bus Simplified Schematic View of a Sun Fire V490 System FIGURE 6-1 Consider also that some diagnostics must function even when the system fails to start. Any diagnostic capable of isolating problems when the system fails to start up must be independent of the operating system.
Page 123: About Diagnostics And The Boot Process
Perhaps you have watched as your console displays messages that look like the following: 0:0> 0:0>@(#) Sun Fire[TM] V480/V490 POST 4.15 2004/04/09 16:27 0:0>Copyright © 2004 Sun Microsystems, Inc. All rights reserved SUN PROPRIETARY/CONFIDENTIAL. Use is subject to license terms. 0:0>Jump from OBP->POST.
Page 124: Prologue: System Controller Boot
Prologue: System Controller Boot As soon as you plug in the Sun Fire V490 server to an electrical outlet, and before you turn on power to the server, the system controller (SC) inside the server begins its self-diagnostic and boot cycle. During this time, the locator LED blinks. Running off standby power, the system controller card begins functioning before the server itself comes up.
Page 125: The Purpose Of Post Diagnostics
POST diagnostics does not ensure that there is nothing wrong with the server, but it does ensure that the server can proceed to the next stage of the boot process. For a Sun Fire V490 server, this means: At least one of the processors is working. ■...
Page 126: What Post Diagnostics Do
The specific circuit or subcomponent that is most likely at fault ■ The field-replaceable units (FRUs) most likely to require replacement, in order of ■ likelihood Here is an excerpt of POST output showing another error message. Sun Fire V490 Server Administration Guide • October 2005...
Page 127: Figure 6-3 Post Diagnostic Running Across Frus
FRU is responsible. If this seems counter-intuitive, consider the block diagram of one data path within a Sun Fire V490 server, shown in FIGURE 6-3 5-way...
Page 128: Controlling Post Diagnostics
OpenBoot PROM Enhancements for Diagnostic Operation and OpenBoot 4.x Command Reference Manual. The former is included on the Sun Fire V490 Documentation CD. The latter is included with the Solaris Software Supplement CD that ships with Solaris software.
Page 129: Table 6-2 Openboot Configuration Variables
The level of test coverage, verbosity, and output is determined by user-defined settings. Note: The above behaviors only apply to server machines like the Sun Fire V490 server. Workstations behave differently. For details, refer to OpenBoot PROM Enhancements for Diagnostic Operation.
Page 130 OpenBoot configuration variables. Note: If the system control switch is in Diagnostics position, the system will boot in service mode even if the service-mode? variable is false. Sun Fire V490 Server Administration Guide • October 2005...
Page 131: Stage Two: Openboot Diagnostics Tests
OpenBoot Diagnostics tests focus on system I/O and peripheral devices. Any device in the device tree, regardless of manufacturer, that includes an IEEE 1275-compatible self-test is included in the suite of OpenBoot Diagnostics tests. On a Sun Fire V490 server, OpenBoot Diagnostics test the following system components: I/O interfaces;...
Page 132: Table 6-3 Keywords For The Test-Args Openboot Configuration Variable
The obdiag> prompt and the OpenBoot Diagnostics interactive menu ( FIGURE 6-4 appear. For a brief explanation of each OpenBoot Diagnostics test, refer to TABLE 6-10 “Reference for OpenBoot Diagnostics Test Descriptions” on page 109. Sun Fire V490 Server Administration Guide • October 2005...
Page 133: Figure 6-4 Openboot Diagnostics Interactive Test Menu
o b d i a g 1 SUNW,qlc@2 2 bbc@1,0 3 ebus@1 4 flashprom@0,0 5 i2c@1,2e 6 i2c@1,30 7 ide@6 8 network@1 9 network@2 10 pmc@1,300700 11 rsc-control@1,3062f8 12 rtc@1,300070 14 usb@1,3 13 serial@1,400000 Commands: test test-all except help what setenv set-default exit diag-passes=1 diag-level=off test-args=subtests OpenBoot Diagnostics Interactive Test Menu FIGURE 6-4...
Page 134: What Openboot Diagnostics Error Messages Tell You
Note – Knowing how to construct an appropriate hardware device path requires precise knowledge of the hardware architecture of the Sun Fire V490 system. To customize an individual test, you can use test-args as follows: ok test /usb@1,3:test-args={verbose,debug} This affects only the current test without changing the value of the test-args OpenBoot configuration variable.
Page 135: I2C Bus Device Tests
Beyond the formal firmware-based diagnostic tools, there are a few commands you can invoke from the ok prompt. These OpenBoot commands display information that can help you assess the condition of a Sun Fire V490 server. These include the following commands:...
Page 136 The probe-scsi command communicates with all SCSI and FC-AL devices connected to on-board SCSI and FC-AL controllers. The probe-scsi-all command additionally accesses devices connected to any host adapters installed in PCI slots. Sun Fire V490 Server Administration Guide • October 2005...
Page 137 For any SCSI or FC-AL device that is connected and active, the probe-scsi and probe-scsi-all commands display its loop ID, host adapter, logical unit number, unique World Wide Name (WWN), and a device description that includes type and manufacturer. The following is sample output from the probe-scsi command. probe-scsi Command Output CODE EXAMPLE 6-3 ok probe-scsi...
Page 138 (edited for CODE EXAMPLE 6-6 brevity). show-devs Command Output CODE EXAMPLE 6-6 /pci@9,600000 /pci@9,700000 /pci@8,600000 /pci@8,700000 /memory-controller@3,400000 /SUNW,UltraSPARC-IV@3,0 /memory-controller@1,400000 /SUNW,UltraSPARC-IV@1,0 /virtual-memory /memory@m0,20 /pci@9,600000/SUNW,qlc@2 /pci@9,600000/network@1 /pci@9,600000/SUNW,qlc@2/fp@0,0 /pci@9,600000/SUNW,qlc@2/fp@0,0/disk Sun Fire V490 Server Administration Guide • October 2005...
Page 139: Stage Three: The Operating System
Solaris system administration documentation. Solaris System Information Commands Some Solaris commands display data that you can use when assessing the condition of a Sun Fire V490 server. These include the following commands: prtconf command ■ prtdiag command ■...
Page 140: Prtconf Command
The display format used by the prtdiag command can vary depending on what version of the Solaris OS is running on your system. Following is an excerpt of some of the output produced by prtdiag on a healthy Sun Fire V490 system running Solaris 8, Update 7.
Page 141 Command Output CODE EXAMPLE 6-8 System Configuration: Sun Microsystems sun4u Sun Fire V490 System clock frequency: 150 MHz Memory size: 4096 Megabytes ========================= CPUs =============================================== Impl. Mask ---- ------- ---- US-IV 2.1 US-IV 2.1 ========================= Memory Configuration =============================== Logical...
Page 142: Prtfru Command
[FAULT] prtfru Command The Sun Fire V490 system maintains a hierarchical list of all field-replaceable units (FRUs) in the system, as well as specific information about various FRUs. The prtfru command can display this hierarchical list, as well as data contained in the serial electrically-erasable programmable read-only memory (SEEPROM) devices located on many FRUs.
Page 143 FRU description ■ Manufacturer name and location ■ Part number and serial number ■ Hardware revision levels ■ Information about the following Sun Fire V490 FRUs is displayed by the prtfru command: Centerplane ■ CPU/Memory boards ■ DIMMs ■ FC-AL disk backplane ■...
Page 144: Psrinfo Command
Kernel version: SunOS 5.8 cstone_14:08/01/01 2001 When used with the -p option, this command displays installed patches. shows a partial sample output from the showrev command with CODE EXAMPLE 6-16 the -p option. Sun Fire V490 Server Administration Guide • October 2005...
Page 145: Tools And The Boot Process: A Summary
showrev -p Command Output CODE EXAMPLE 6-16 Patch: 109729-01 Obsoletes: Requires: Incompatibles: Packages: SUNWcsu Patch: 109783-01 Obsoletes: Requires: Incompatibles: Packages: SUNWcsu Patch: 109807-01 Obsoletes: Requires: Incompatibles: Packages: SUNWcsu Patch: 109809-01 Obsoletes: Requires: Incompatibles: Packages: SUNWcsu Patch: 110905-01 Obsoletes: Requires: Incompatibles: Packages: SUNWcsu Patch: 110910-01 Obsoletes: Requires:...
Page 146: About Isolating Faults In The System
(FRUs). The row headings along the left of list the FRUs TABLE 6-5 in a Sun Fire V490 system. The available diagnostic tools are shown in column ✔ ) in this table indicates that a fault in a headings across the top. A check mark ( particular FRU can be isolated by a particular diagnostic.
Page 147: About Monitoring The System
In addition to the FRUs listed in , there are several minor replaceable TABLE 6-5 system components—mostly cables—that cannot directly be isolated by any system diagnostic. For the most part, you determine when these components are faulty by eliminating other possibilities. These FRUs are listed in TABLE 6-6 FRUs Not Directly Isolated by Diagnostic Tools TABLE 6-6...
Page 148: Monitoring The System Using Remote System Control Software
Before you can start using RSC software, you must install and configure it on the server and client systems. Instructions for doing this are given in the Sun Remote System Control (RSC) 2.2 User’s Guide, which is included on the Sun Fire V490 Documentation CD.
Page 149: Monitoring The System Using Sun Management Center
For instructions on using RSC software to monitor a Sun Fire V490 system, refer to “How to Monitor the System Using the System Controller and RSC Software” on page 190. Monitoring the System Using Sun Management Center Sun Management Center software provides enterprise-wide monitoring of Sun servers and workstations, including their subsystems, components, and peripheral devices.
Page 150: Other Sun Management Center Features
If you administer a heterogeneous network and use a third-party network-based system monitoring or management tool, you may be able to take advantage of Sun Management Center software’s support for Tivoli Enterprise Console, BMC Patrol, and HP Openview. Sun Fire V490 Server Administration Guide • October 2005...
Page 151: Who Should Use Sun Management Center
Sun provides two tools for exercising Sun Fire V490 systems: Sun Validation Test Suite (SunVTS™) ■...
Page 152: Exercising The System Using Sunvts Software
For typical system configurations, this requires one or two hours. Comprehensive testing – SunVTS software exhaustively and repeatedly tests all ■ subsystems for up to 24 hours. Sun Fire V490 Server Administration Guide • October 2005...
Page 153 The Sun Fire V490 server to be tested must be up and running if you want to use SunVTS software, since it relies on the Solaris operating system. Since SunVTS software packages are optional, they may not be installed on your system.
Page 154: Sunvts Software And Security
If the faulty part is hot-pluggable or hot-swappable, the entire diagnose-and-repair cycle can be completed with minimal impact to system users. Sun Fire V490 Server Administration Guide • October 2005...
Page 155: Requirements For Using Hardware Diagnostic Suite
Requirements for Using Hardware Diagnostic Suite Since it is a part of Sun Management Center, you can only run Hardware Diagnostic Suite if you have set up your data center to run Sun Management Center. This means you have to dedicate a master server to run the Sun Management Center server software that supports Sun Management Center software’s database of platform status information.
Page 156: Table 6-11 Openboot Diagnostics Test Menu Commands
(A similar function is available from the ok prompt. Refer to “From the ok Prompt: The test and test-all Commands” on page 87.) Tests only the devices identified by the given menu entry test #,# numbers Sun Fire V490 Server Administration Guide • October 2005...
Page 157: Reference For Decoding I2C Diagnostic Test Messages
Reference for Decoding I C Diagnostic Test Messages describes each I C device in a Sun Fire V490 system, and helps you TABLE 6-12 associate each I C address with the proper FRU. For more information about I tests, refer to “I2C Bus Device Tests”...
Page 158 CPU/Memory board in slot A fru@4,a2 CPU/Mem Board, slot B Provides configuration information for the CPU/Memory board in slot B nvram@4,a4 PCI riser Provides system configuration information (IDPROM) fru@4,a8 Centerplane Provides centerplane configuration information Sun Fire V490 Server Administration Guide • October 2005...
Page 159 Sun Fire V490 I C Bus Devices (Continued) TABLE 6-12 Address Associated FRU What the Device Does fru@4,aa PCI riser Provides PCI riser board configuration information fru@5,10 Centerplane Provides communication and control for C subsystem fru@5,14 RSC card Provides communication and control for...
Page 160: Reference For Terms In Diagnostic Output
(1149.1) for scanning system components Media Access Controller – Hardware address of a Centerplane device connected to a network Media Independent Interface – Part of Ethernet Centerplane controller Motherboard Centerplane Centerplane Sun Fire V490 Server Administration Guide • October 2005...
Page 161 Abbreviations or Acronyms in Diagnostic Output (Continued) TABLE 6-13 Term Description Associated FRU(s) NVRAM IDPROM IDPROM, located on PCI riser board Refers to OpenBoot firmware Power Distribution Board Power distribution board Power Management Controller PCI riser board POST Power-On Self-Test Multifunction integrated circuit bridging the PCI PCI riser board bus with EBus and USB...
Page 162 Sun Fire V490 Server Administration Guide • October 2005...
Page 163 III Instructions PA RT The six chapters within this part of the Sun Fire V490 Server Administration Guide use illustrated instructions on how to set up various components within your system, configure your system, and diagnose problems. Instructions within this guide are primarily to be used by experienced system administrators who are familiar with the Solaris OS and its commands.
Page 165: Configuring Console Access
C H A P T E R Configuring Console Access This chapter includes instructions on how to configure and access the system console from different physical devices. Tasks covered in this chapter include: “How to Avoid Electrostatic Discharge” on page 120 ■...
Page 166: How To Avoid Electrostatic Discharge
Caution – Do not attempt to access any internal components unless you are a qualified service technician. Detailed service instructions can be found in the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD.
Page 167 2. Use an antistatic mat or similar surface. When performing any installation or service procedure, place static-sensitive parts, such as boards, cards, and disk drives, on an antistatic surface. The following items can be used as an antistatic surface: The bag used to wrap a Sun replacement part ■...
Page 168: What Next
Read the documentation supplied with the device for specific instructions. 2. Turn on power to the ASCII terminal or local graphics terminal, if present. 3. Open the media door. Use the system key to unlock the media door. Sun Fire V490 Server Administration Guide • October 2005...
Page 169 Media door 4. Insert the system key into the system control switch and turn the system control switch to the Normal position. Refer to “System Control Switch” on page 15 for information about each system control switch setting. Normal position Power button 5.
Page 170: What Next
7. Remove the system key from the system control switch and keep it in a secure place. What Next To power off the system, complete this task: “How to Power Off the System” on page 125 ■ Sun Fire V490 Server Administration Guide • October 2005...
Page 171: How To Power Off The System
How to Power Off the System Before You Begin Applications running on the Solaris OS can be adversely affected by a poorly executed system shutdown. Make sure that you have gracefully shut down any applications before powering off the system. You can also use Solaris commands, the OpenBoot firmware power-off command, or RSC software to power off the system.
Page 172: What Next
Note – Do not attempt to access any internal components unless you are a qualified service technician. Detailed service instructions can be found in the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD.
Page 173: What To Do
If at all possible, back up system data before starting this procedure. Also halt all applications and warn users of the impending loss of service. For information about the appropriate backup and shutdown procedures, refer to Solaris system administration documentation. What to Do 1.
Page 174: What To Do
Install the server in the rack, following instructions in the Sun Fire V490 Server ■ Setup and Rackmounting Guide. What to Do 1. Locate the RJ-45 twisted-pair Ethernet (TPE) connector for the appropriate Ethernet interface—the top connector or the bottom connector.
Page 175: How To Access The System Console Via Tip Connection
The following procedure assumes you are connecting to the serial port (ttya) of the Sun Fire V490 system using a tip connection from serial port B (ttyb) of another Sun server, and that the other Sun server has its own local graphics terminal.
Page 176: What Next
The Sun server responds by displaying: connected The terminal tool is now a tip window directed to the Sun Fire V490 system via the Sun server’s ttyb port. This connection is established and maintained even if the Sun Fire V490 system is completely powered off or just starting up.
Page 177: How To Modify The /Etc/Remote File
Before You Begin This procedure assumes you are connecting via tip line from serial port B (ttyb) of a Sun server to the serial port (ttya) of the Sun Fire V490 machine. What to Do 1. Determine the release level of system software installed on the Sun server.
Page 178: What Next
This procedure lets you verify the baud rate and other serial port settings used by the Sun Fire V490 server to communicate with attached serial port devices. Before You Begin You must be logged in to the Sun Fire V490 server, and the server must be running Solaris OS software. What to Do 1.
Page 179: What Next
2. Type: # eeprom ttya-mode 3. Look for the following output: ttya-mode = 9600,8,n,1,- This line indicates that the Sun Fire V490 server’s serial port is configured for: 9600 baud ■ 8 bits ■ No parity ■ 1 stop bit ■...
Page 180: What To Do
Use an RJ-45 null modem serial cable or an RJ-45 serial cable and null modem adapter. Plug this into the terminal’s serial port connector. 2. Attach the opposite end of the serial cable to the Sun Fire V490 system. Plug the cable into the system’s built-in serial port (ttya) connector.
Page 181: What Next
Note – Do not attempt to access any internal components unless you are a qualified service technician. Detailed service instructions can be found in the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD.
Page 182: What To Do
1. Install the graphics card into an appropriate PCI slot. Installation must be performed by a qualified service provider. For further information, refer to the Sun Fire V490 Server Parts Installation and Removal Guide or contact your qualified service provider.
Page 183 5. Connect the mouse USB cable to any USB port on the back panel. Chapter 7 Configuring Console Access...
Page 184 7. To cause the changes to take effect, type: ok reset-all The system permanently stores the parameter changes and boots automatically if the OpenBoot variable auto-boot? is set to true (its default value). Sun Fire V490 Server Administration Guide • October 2005...
Page 185: What Next
To issue software commands, you need to set up a system ASCII terminal, a local graphics terminal, or a tip connection to the Sun Fire V490 system. Refer to: “How to Set Up an Alphanumeric Terminal as the System Console” on page 133 ■...
Page 186: What To Do
Boot device: disk2 File and args: c. At this point, abort the boot process as promptly as possible. To do this, use one of the following methods: Sun Fire V490 Server Administration Guide • October 2005...
Page 187: What Next
Hold down the Stop (or L1) key and press A on your keyboard. ■ Press the Break key on the terminal keyboard. ■ Type ~# in a tip window. ■ The system should return to the ok prompt. Note – If the system does not return to the ok prompt, it means you did not abort quickly enough.
Page 188: Reference For System Console Openboot Variable Settings
In addition to the above OpenBoot configuration variables, there are other variables that determine whether and what kinds of diagnostic tests run. These variables are discussed in “Controlling POST Diagnostics” on page Sun Fire V490 Server Administration Guide • October 2005...
Page 189: Configuring Network Interfaces And The Boot Device
Caution – Do not attempt to access any internal components unless you are a qualified service technician. Detailed service instructions can be found in the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD.
Page 190: How To Configure The Primary Network Interface
(-). Do not use a dot in the host name. Do not begin the name with a number or a special character. The name must not be longer than 30 characters. Sun Fire V490 Server Administration Guide • October 2005...
Page 191: What Next
4. Determine the unique Internet Protocol (IP) address of the network interface and make a note of it. You need to furnish the address in a later step. An IP address must be assigned by the network administrator. Each network device or interface must have a unique IP address.
Page 192: How To Configure Additional Network Interfaces
Note – The Sun Fire V490 system conforms to the Ethernet 10/100BASE-T standard, which states that the Ethernet 10BASE-T link integrity test function should always be enabled on both the host system and the Ethernet hub. If you have problems establishing a connection between this system and your hub, verify that the Ethernet hub also has the link test function enabled.
Page 193: What To Do
What to Do 1. Choose a network host name for each new interface. The host name must be unique within the network. It can consist only of alphanumeric characters and the dash (-). Do not use a dot in the host name. Do not begin the name with a number or a special character.
Page 194 7. Manually plumb and enable each new interface using the ifconfig command. For example, for the interface ce2, type: sunrise # ifconfig ce2 plumb up For more information, refer to the ifconfig(1M) man page. Sun Fire V490 Server Administration Guide • October 2005...
Page 195: What Next
This document is available on the Solaris Software Supplement CD for your specific Solaris release. Note – The Sun Fire V490 system conforms to the Ethernet 10/100BASE-T standard, which states that the Ethernet 10BASE-T link integrity test function should always be enabled on both the host system and the Ethernet hub.
Page 196: What To Do
Note – You can also specify the name of the program to be booted as well as the way the boot program operates. For more information, refer to the OpenBoot 4.x Command Reference Manual, included with the Solaris Software Supplement CD that ships with Solaris software. Sun Fire V490 Server Administration Guide • October 2005...
Page 197: What Next
If you want to specify a network interface other than an on-board Ethernet interface as the default boot device, you can determine the full path name of each interface by typing: ok show-devs The show-devs command lists the system devices and displays the full path name of each PCI device.
Page 198 Sun Fire V490 Server Administration Guide • October 2005...
Page 199: Configuring System Firmware
C H A P T E R Configuring System Firmware This chapter describes OpenBoot firmware commands and configuration variables available for configuring the following aspects of Sun Fire V490 system behavior: OpenBoot environmental monitoring ■ Automatic system recovery (ASR) ■...
Page 200: How To Enable Openboot Environmental Monitoring
“How to Disable OpenBoot Environmental Monitoring” on page 154 ■ How to Disable OpenBoot Environmental Monitoring Before You Begin For background information about the OpenBoot environmental monitor, refer to: “About OpenBoot Environmental Monitoring” on page 52 ■ Sun Fire V490 Server Administration Guide • October 2005...
Page 201: What To Do
What to Do ● To disable OpenBoot environmental monitoring, type env-off at the ok prompt: ok env-off Environmental monitor is OFF How to Obtain OpenBoot Environmental Status Information Before You Begin For background information about environmental status information, refer to: “OpenBoot Environmental Status Information”...
Page 202: How To Enable The Watchdog Mechanism And Its Options
To reboot and generate an automated crash dump file, type: ■ # eeprom error-reset-recovery=sync To have the system not automatically reboot, but rather wait at the OpenBoot ■ prompt for manual intervention and recovery, type: # eeprom error-reset-recovery=none Sun Fire V490 Server Administration Guide • October 2005...
Page 203: What Next
3. Restart the system to effect the changes. Type: # reboot What Next If you choose to have the system generate an automated crash dump file, then, in the event the operating system hangs, that file appears in the /var/crash/ directory, under a subdirectory named after your system.
Page 204: What Next
What to Do 1. At the system ok prompt, type: ok setenv auto-boot-on-error? false 2. To cause the parameter change to take effect, type: ok reset-all The system permanently stores the parameter change. Sun Fire V490 Server Administration Guide • October 2005...
Page 205: How To Obtain Asr Status Information
How to Obtain ASR Status Information Use the following procedure to retrieve information about the status of the automatic system recovery (ASR) feature. What to Do 1. At the system ok prompt, type: ok .asr In the .asr command output, any devices marked disabled have been manually deconfigured using the asr-disable command.
Page 206: How To Redirect The System Console To The System Controller
1. Establish a system controller session. For instructions, refer to the Sun Remote System Control (RSC) 2.2 User’s Guide, which is included on the Sun Fire V490 Documentation CD. 2. At the system ok prompt, type: ok setenv diag-out-console true...
Page 207: What Next
For instructions on how to use RSC software, refer to: Sun Remote System Control (RSC) 2.2 User’s Guide, which is included on the Sun ■ Fire V490 Documentation CD How to Restore the Local System Console Perform this procedure if your system is configured to use the system controller (SC) as the system console and you need to redirect the system console to a local graphics terminal, alphanumeric terminal, or an established tip connection.
Page 208: What Next
“status” property in the corresponding device tree node. By convention, UNIX will not activate a driver for any device so marked. For background information, refer to “About Manually Configuring Devices” on page 59 ■ Sun Fire V490 Server Administration Guide • October 2005...
Page 209: What To Do
What to Do 1. At the system ok prompt, type: ok asr-disable device-identifier where the device-identifier is one of the following: Any full physical device path as reported by the OpenBoot show-devs command ■ Any valid device alias as reported by the OpenBoot devalias command ■...
Page 210: What To Do
This procedure implements Stop-N functionality on Sun Fire V490 systems, temporarily resetting OpenBoot configuration variables to their default settings. This procedure is most useful if you have not configured your Sun Fire V490 system to run diagnostic tests. You might find it more convenient to use the alternative method of placing the system control switch in the Diagnostics position.
Page 211: What To Do
2. Wait until only the system Fault LED begins to blink rapidly. Note – If you have configured the Sun Fire V490 system to run diagnostic tests, this could take upwards of 30 minutes. 3. Press the front panel Power button twice, with no more than a short, one-second delay in between presses.
Page 212: What Next
To correct such problems, you must either manually change individual OpenBoot configuration variables using the setenv command, or else type set-defaults to permanently restore the default settings for all OpenBoot configuration variables. Sun Fire V490 Server Administration Guide • October 2005...
Page 213: Isolating Failed Parts
This chapter guides you in choosing the best tools and describes how to use these tools to reveal a failed part in your Sun Fire V490 server. It also explains how to use the Locator LED to isolate a failed system in a large equipment room.
Page 214: How To Operate The Locator Led
Caution – Do not attempt to access any internal components unless you are a qualified service technician. Detailed service instructions can be found in the Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the Sun Fire V490 Documentation CD.
Page 215 As root, type ■ # /usr/sbin/locator -n At the SC command-line interface, type: ■ rsc> setlocator on From the RSC software’s main GUI screen, click the representation of the ■ Locator LED. Refer to the illustration under Step 5 “How to Monitor the System Using the System Controller and RSC Software”...
Page 216: How To Put The Server In Service Mode
For a full description of service mode, refer to: OpenBoot PROM Enhancements for Diagnostic Operation ■ This document is included on the Sun Fire V490 Documentation CD. What to Do 1. Set up a console for viewing diagnostic messages. Access the system console using an ASCII terminal or tip line. For information on system console options, refer to “About Communicating With the System”...
Page 217: What Next
What Next Should you want to restore the system to normal mode in order to control the depth of diagnostic coverage, the tests run, and the verbosity of the output, refer to: “How to Put the Server in Normal Mode” on page 171.
Page 218: What Next
For detailed descriptions of service and normal modes, refer to: OpenBoot PROM Enhancements for Diagnostic Operation ■ This document is included on the Sun Fire V490 Documentation CD. How to Isolate Faults Using LEDs While not a deep, formal diagnostic tool, LEDs located on the chassis and on selected system components can serve as front-line indicators of a limited set of hardware failures.
Page 219: What To Do
What to Do 1. Check the system LEDs. There is a group of three LEDs located near the top left corner of the front panel and duplicated on the back panel. Their status can tell you the following. Indicates Action Locator (left) A system administrator can Identify the system.
Page 220: What Next
There are two LEDs for each Ethernet port—they are close to the right side of each Ethernet receptacle on the back panel. If the Sun Fire V490 system is connected to an Ethernet network, the status of the Ethernet LEDs can tell you the following.
Page 221: How To Isolate Faults Using Post Diagnostics
What to Do 1. Set up a console for viewing POST messages. Connect an alphanumeric terminal to the Sun Fire V490 server or establish a tip connection to another Sun system. Refer to: “How to Set Up an Alphanumeric Terminal as the System Console” on page 133 ■...
Page 222: What Next
Have a qualified service technician replace the FRU or FRUs indicated by POST error messages, if any. For replacement instructions, refer to: Sun Fire V490 Server Parts Installation and Removal Guide, which is included on the ■ Sun Fire V490 Documentation CD If the POST diagnostics did not disclose any problems, but your system does not start, try running the interactive OpenBoot Diagnostics tests.
Page 223: How To Isolate Faults Using Interactive Openboot Diagnostics Tests
How to Isolate Faults Using Interactive OpenBoot Diagnostics Tests Before You Begin Because OpenBoot Diagnostics tests require access to some of the same hardware resources used by the operating system, they cannot be operated reliably after an operating system halt or Stop-A key sequence. You need to reset the system before running OpenBoot Diagnostics tests, and then reset the system again after testing.
Page 224: What Next
Diagnostics error messages, if any. For replacement instructions, refer to: Sun Fire V490 Server Parts Installation and Removal Guide ■ This document is included on the Sun Fire V490 Documentation CD. Sun Fire V490 Server Administration Guide • October 2005...
Page 225: How To View Diagnostic Test Results After The Fact
How to View Diagnostic Test Results After the Fact Summaries of the results from the most recent power-on self-test (POST) and OpenBoot Diagnostics tests are saved across power cycles. Before You Begin You must set up a system console. Refer to: “About Communicating With the System”...
Page 226: How To View And Set Openboot Configuration Variables
Variable Name Value Default Value diag-level diag-switch? false false ● To set or change the value of an OpenBoot configuration variable, use the setenv command: ok setenv diag-level max diag-level = max Sun Fire V490 Server Administration Guide • October 2005...
Page 227: What Next
Reference for Choosing a Fault Isolation Tool This section helps you choose the right tool to isolate a failed part in a Sun Fire V490 system. Consider the following questions when selecting a tool. 1. Have you checked the LEDs? Certain system components have built-in LEDs that can alert you when that component requires replacement.
Page 228: Figure 10-1 Choosing A Tool To Isolate Hardware Faults
In addition, RSC software provides a means of redirecting system console output, allowing you remotely to view and run tests—like POST diagnostics—that usually require physical proximity to the serial port on the system’s back panel. Sun Fire V490 Server Administration Guide • October 2005...
Page 229 5. Will the tool test the suspected source(s) of the problem? Perhaps you already have some idea of what the problem is. If so, you want to use a diagnostic tool capable of testing the suspected problem sources. tells you which replaceable hardware parts can be isolated by each TABLE 6-5 ■...
Page 230 Sun Fire V490 Server Administration Guide • October 2005...
Page 231: Monitoring The System
This chapter describes the tasks necessary to use these tools to monitor your Sun Fire V490 server. These include: “How to Monitor the System Using Sun Management Center Software” on ■...
Page 232: How To Monitor The System Using Sun Management Center Software
Before You Begin This procedure assumes you intend to load Sun Management Center agent software on your Sun Fire V490 system so as to be able to monitor it, and gives you some guidance on how to accomplish this goal.
Page 233: What To Do
For instructions, refer to the Sun Management Center Supplement for Workgroup Servers. 2. On your Sun Fire V490 system, run the setup utility to configure agent software. The setup utility is part of the workgroup server supplement. For more information, refer to the Sun Management Center Supplement for Workgroup Servers.
Page 234 Status information about selected component For more information about physical and logical views, refer to the Sun Management Center User’s Guide. Sun Fire V490 Server Administration Guide • October 2005...
Page 235 7. Monitor the Sun Fire V490 system using Config-Reader module data property tables. To access this information: a. Click the Browser tab. b. Click the Hardware icon in the hierarchy view. Browser tab Hardware icon Conﬁg-Reader icon Data property table icons c.
Page 236: What Next
Before You Begin The Sun Fire V490 server must be set up with RSC server software, which can be found on the Solaris Software Supplement CD. Typically, you monitor the Sun Fire V490 system from a different Sun computer or a PC. This procedure assumes you have installed RSC client software on the monitoring system.
Page 237: What To Do
What to Do 1. As root on the Sun Fire V490 server, run the RSC configuration script. Type: # /usr/platform/‘uname -i‘/rsc/rsc-config The configuration script runs, prompting you to choose options and to provide information. 2. Follow the configuration script prompts.
Page 238 Setting User Password Now ... Password: Re-enter Password: The RSC firmware on the Sun Fire V490 system is configured. Perform the following steps on the monitoring system. 3. From the monitoring Sun computer or PC, start the RSC GUI. Do one of the following.
Page 239 This front panel representation is dynamic—you can watch from a remote console and refer to when the Sun Fire V490 server’s switch settings or LED status changes. 6. Interact with the front panel representation to initiate actions. The front panel representation is interactive. You click various parts of it to initiate actions.
Page 240 Proceeding will actually turn system power off (or on). Power button b. Examine status tables for the Sun Fire V490 server’s disks and fans. Click the appropriate LEDs. A table appears giving you the status of the components in question.
Page 241 a. Find the navigation panel at the left side of the RSC GUI. b. Click the Show Environmental Status item under Server Status and Control. The Environmental Status window appears. Check marks By default, the Temperatures tab is selected and temperature data from specific chassis locations are graphed.
Page 242: What Next
160. What Next If you plan to use RSC software to control the Sun Fire V490 server, you may want to configure additional RSC user accounts. If you want to try the system controller command-line interface, you can use the telnet command to connect directly to the RSC card using the device’s name or IP...
Page 243: How To Use Solaris System Information Commands
How to Use Solaris System Information Commands This section explains how to run Solaris system information commands on a Sun Fire V490 server. To find out what these commands tell you, refer to “Solaris System Information Commands” on page 93, or refer to the appropriate man pages.
Page 244: How To Use Openboot Information Commands
How to Use OpenBoot Information Commands This section explains how to run OpenBoot commands that display different kinds of system information about a Sun Fire V490 server. To find out what these commands tell you, refer to “Other OpenBoot Commands” on page 89, or refer to the appropriate man pages.
Page 245: Table 11-2 Using Openboot Information Commands
3. Type the appropriate command at a console prompt. Refer to TABLE 11-2 Using OpenBoot Information Commands TABLE 11-2 Command to Type What It Displays Fan speeds, currents, voltages, and temperatures .env OpenBoot configuration variable defaults and settings printenv Target address, unit number, device type, and manufacturer name probe-scsi of active SCSI, IDE, and FC-AL devices probe-scsi-all...
Page 246 Sun Fire V490 Server Administration Guide • October 2005...
Page 247: Exercising The System
Sun Management Center Software User’s Guide. This chapter describes the tasks necessary to use SunVTS software to exercise your Sun Fire V490 server. These include: “How to Exercise the System Using SunVTS Software” on page 202 ■...
Page 248: How To Exercise The System Using Sunvts Software
“Exercising the System Using SunVTS Software” on page 106 ■ This procedure also assumes that the Sun Fire V490 server is “headless”—that is, it is not equipped with a monitor capable of displaying bitmapped graphics. In this case, you access the SunVTS GUI by logging in remotely from a machine that has a graphics display.
Page 249: What To Do
2. Enable remote display. On the display system, type: # /usr/openwin/bin/xhost + test-system where test-system is the name of the Sun Fire V490 server being tested. 3. Remotely log in to the Sun Fire V490 server as superuser. Use a command such as rlogin or telnet.
Page 250 5. Expand the test lists to refer to the individual tests. The interface’s test selection area lists tests in categories, such as “Network,” as shown below. To expand a category, click the icon to the left of the category name. Sun Fire V490 Server Administration Guide • October 2005...
Page 251: Table 12-1 Useful Sunvts Tests To Run On A Sun Fire V490 Server
Tests are enabled when checked, and disabled when not checked. lists tests that are especially useful to run on a Sun Fire V490 server. TABLE 12-1 Useful SunVTS Tests to Run on a Sun Fire V490 Server...
Page 252: What Next
In addition to the SunVTS packages themselves, SunVTS software starting with version 5.1 requires certain XML and run-time library packages that may not be installed by default on Solaris 8 software. Sun Fire V490 Server Administration Guide • October 2005...
Page 253: What To Do
This procedure assume that the Solaris operating system is running on the Sun Fire V490 server, and that you have access to the Solaris command line. For more information, refer to: “About Communicating With the System” on page 69 ■ What to Do 1.
Page 254: What Next
These patches provide enhancements and bug fixes. In some cases, there are tests that will not run properly unless the patches are installed. What Next For installation information, refer to the SunVTS User’s Guide, the appropriate Solaris documentation, and the pkgadd man page. Sun Fire V490 Server Administration Guide • October 2005...
Page 255 IV Appendixes PA RT The two appendices within this part of the Sun Fire V490 Server Administration Guide illustrate and describe signals at connector pinouts and list specifications. Appendices included in Part Four are: Appendix A – Connector Pinouts ■...
Page 257: Connector Pinouts
A P P E N D I X Connector Pinouts This appendix gives you reference information about the system’s back panel ports and pin assignments. Topics covered in this appendix include: “Serial Port Connector” on page 212 ■ “USB Connector” on page 213 ■...
Page 258: Serial Port Connector
Serial Port Connector Diagram Serial Port Connector Signals Signal Description Signal Description Request To Send Ground Data Terminal Ready Receive Data Transmit Data Data Set Ready Ground Clear To Send Sun Fire V490 Server Administration Guide • October 2005...
Page 259: Usb Connector
USB Connector Two Universal Serial Bus (USB) connectors are located on the centerplane and can be accessed from the back panel. USB Connector Diagram USB Connector Signals Signal Description Signal Description +5 VDC +5 VDC Port Data0 - Port Data1 - Port Data0 + Port Data1 + Ground...
Page 260: Twisted-Pair Ethernet Connector
TPE Connector Signals Signal Description Signal Description Transmit/Receive Data0 + Transmit/Receive Data2 – Transmit/Receive Data0 – Transmit/Receive Data1 – Transmit/Receive Data1 + Transmit/Receive Data3 + Transmit/Receive Data2 + Transmit/Receive Data3 – Sun Fire V490 Server Administration Guide • October 2005...
Page 261: Sc Ethernet Connector
SC Ethernet Connector The System Controller (SC) Ethernet connector is an RJ-45 connector located on the SC card and can be accessed from the back panel. SC Ethernet Connector Diagram SC Ethernet Connector Signals Signal Description Signal Description Transmit/Receive Data0 + Transmit/Receive Data2 - Transmit/Receive Data0 - Transmit/Receive Data1 -...
Page 262: Sc Serial Connector
SC Serial Connector Diagram SERIAL SC Serial Connector Signals Signal Description Signal Description Request To Send Ground Data Terminal Ready Receive Data Transmit Data Data Set Ready Ground Clear To Send Sun Fire V490 Server Administration Guide • October 2005...
Page 263: Fc-Al Port Hssdc Connector
FC-AL Port HSSDC Connector The Fibre Channel-Arbitrated Loop port high-speed serial data connector is located on the centerplane and can be accessed from the back panel. HSSDC Connector Diagram HSSDC Connector Signal Signal Description Signal Description Differential Data Output + Optical Output Disable (optional) Signal Ground (optional)
Page 264 Sun Fire V490 Server Administration Guide • October 2005...
Page 265: System Specifications
A P P E N D I X System Specifications This appendix provides the following specifications for the Sun Fire V490 Server server: “Physical Specifications” on page 219 ■ “Electrical Specifications” on page 220 ■ “Environmental Specifications” on page 221 ■...
Page 266: Electrical Specifications
Nominal Frequencies 50 or 60 Hz Nominal Voltage Range Auto Ranging 200-240 VAC Maximum Current AC RMS 8A @ 200-240 VAC Maximum AC Power Consumption 1600 W Maximum Heat Dissipation 5459 BTU/hr Sun Fire V490 Server Administration Guide • October 2005...
Page 267: Environmental Specifications
Environmental Specifications The operating and non-operating environmental specifications for the system are as follows. Parameter Value Operating Temperature 5˚ C to 35˚C (41˚F to 95˚F)—IEC 60068-2-1&2 Humidity 20% to 80% RH noncondensing; 27˚C (81˚F) wet bulb— IEC 60068-2-3&56 Altitude 0 to 3000 meters (0 to 10,000 feet)—IEC 60068-2-13 Vibration .0001 (z-axis only) G /Hz, 5-150 Hz, -12db/octave slope,...
Page 268: Agency Compliance Specifications
36 in (92 cm) Rear blockage only 36 in (92 cm) Front and rear blockage 36 in (92 cm) Front clearance 36 in (92 cm) Rear clearance 36 in (92 cm) Sun Fire V490 Server Administration Guide • October 2005...
Page 269 Index BIST, See built-in self-test BMC Patrol, See third-party monitoring tools AC Present LED (power supply), 173 boot device, how to select, 149 accounts RSC, 191 Boot PROM function of, 78 Activity LED illustration of, 79 disk drive, 174 Ethernet, 174 boot-device conﬁguration variable, 57, 149 address booting...
Page 270 (XIR), 51, 127 mirroring, 24, 66 described, 23 RAID 0, 24, 67 manual command, 23 RAID 1, 24, 67 RAID 5, 24, 68 striping, 24, 67 disk drive Sun Fire V490 Server Administration Guide • October 2005...
Page 271 displaying speed of, 90 boundaries between, 82 Fan Tray 0 coverage of fault isolating tools (table), 100 isolating faults in cable, 101 coverage of system exercising tools (table), 106 Fan Tray 0 LED hardware revision level, 97 described, 14 hierarchical list of, 96 Fan Tray 1 LED manufacturer, 97 described, 14...
Page 272 14, 173 Fan Tray 0 described, 14 network name server, 149 Fan Tray 1 described, 14 primary interface, 145 types, 4 Fault, 14 Fault (disk drive), 174 Fault (power supply), 173 Sun Fire V490 Server Administration Guide • October 2005...
Page 273 overtemperature condition determining with prtdiag, 96 OBDIAG, See OpenBoot Diagnostics tests determining with RSC, 195 ok prompt risks in using, 50 ways to access, 50, 126 parity, 24, 68, 133, 134 OK-to-Remove LED parts disk drive, 174 checklist of, 1 power supply, 173 patches, installed OpenBoot commands...
Page 274 23, 127 electrical, 220 main screen, 193 environmental, 221 monitoring with, 190 physical, 219 run levels service access, 222 explained, 49 standby power ok prompt and, 49 RSC and, 102 status LEDs Sun Fire V490 Server Administration Guide • October 2005...
Page 275 environmental fault indicators, 21 Stop-A keyboard combination, 51, 54, 127 temperature sensors, 20 Stop-D keyboard combination, 54 temperatures, displaying system, 90 Stop-F keyboard combination, 55 terminal, alphanumeric, 133 Stop-N keyboard combination, 165 terminal, baud veriﬁcation, 132 stress testing, See also exercising the system, 106 terms in diagnostic output (table), 114 striping of disks, 24, 67...
Page 276 Sun Fire V490 Server Administration Guide • October 2005...

Sun Microsystems Sun Fire V490 Administration Manual

Regulatory Compliance Statements

Safety Agency Compliance Statements

Preface

1 Sun Fire V490 Server Installation

2 System Overview

3 Hardware Configuration

4 Network Interfaces and System Firmware

5 System Administration Software

6 Diagnostic Tools

7 Configuring Console Access

8 Configuring Network Interfaces and the Boot Device

9 Configuring System Firmware

Quick Links

Need help?

Questions and answers

Related Manuals for Sun Microsystems Sun Fire V490

Summary of Contents for Sun Microsystems Sun Fire V490
