The power supplies operate over an AC input range of 100 240 VAC, 47-63 Hz. Each
power supply can provide up to 550 watts of 12V DC power. Each power supply
contains a series of status indicators, visible when looking at the back panel of the
system.
FIGURE 4-6
See
TABLE 4-5
from top to bottom.
TABLE 4-5
Indicator
DC Power On
Service Required
AC Power Present
Note – If a power supply is faulty, the system Service Required indicator is also lit.
See "Front Panel Indicators" on page 10
90 Sun Fire V445 Server Administration Guide • September 2007
shows the location of the power supplies and indicators.
FIGURE 4-6
Power Supplies and Indicators
for a description of power supply indicators and their function, listed
Power Supply Status Indicators
Color
Green
Amber
Green
DC Power On
Service Required
AC Power Present
Notes
This indicator is lit when the system is powered on and
the power supply is operating normally.
This indicator is lit if there is a fault in the power supply.
This indicator is lit when the power supply is plugged in
and AC power is available, regardless of system power
state.
for more information.
