Figure 4-5 Hard Disk Drives And Indicators - Sun Microsystems Sun Fire V445 Server Administration Manual

FIGURE 4-5
See
TABLE 4-4
TABLE 4-4
LED
OK-to-Remove
Unused
Activity
Note – If a hard disk drive is faulty, the system Service Required indicator is also lit.
See "Front Panel Indicators" on page 10
The hot-plug feature of the system's internal hard disk drives enables you to add,
remove, or replace disks while the system continues to operate. This capability
significantly reduces system downtime associated with hard disk drive replacement.
88 Sun Fire V445 Server Administration Guide • September 2007
Power/Access
Service Required
OK-to-Remove
Hard Disk Drives and Indicators
for a description of hard disk drive indicators and their function.
Hard Disk Drive Status Indicators
Color
Blue
Amber
Green
Description
On - The drive is read for hot-plug removal.
Off - Normal operation.
On - Drive is receiving power. Solidly lit ifdrive is
idle. Flashes while the drive processes a command.
Off - Power is off.
for more information.
