Mounting the Processor Drawer in the Cabinet
After you install the rails on both the cabinet and the processor drawer,
insert the drawer into the cabinet.
Mounting the Processor Drawer in the Cabinet
Pull the inner cabinet mounting rails (in the cabinet) all the way
1.
forward until the retaining latches lock the rails in the "out" position.
Lift the processor drawer to the same height as the mounting rails and
2.
align the rails on the drawer with the cabinet mounting rails. See
Figure 7.
Figure 7: Installing the Processor Drawer
Note:
The processor drawer is
heavy. To prevent injury and
possible damage to the
equipment, we
recommended that you
have assistance when
trying to mount the drawer
into the cabinet.
Installing the Processor Drawer 11
