6 Gateway ALR 8200R User's Guide

Reinstalling the Top Cover

This procedure assumes that you have removed the top cover entirely. If you
opened the top cover, but did not remove it, close the cover and refer to
Step 3 only.
Position the top cover on the chassis, aligning the three holes on each
1.
side and four holes in back.
2. Reinstall the screws removed when the top cover was removed (three
on each side and four in back).
Turn the three slotted retainers 90 degrees clockwise to secure the
3.
front portion of the top cover in place.
Figure 3: Reinstalling the Top Cover
Replacing the Top Cover
