3. If the mounting rails have not previously been installed, position the
drawer template in the cabinet/rack so that the side matches the
corresponding side you wish to install.
Figure 5: Mounting the Brackets on the Cabinet
Mark the screw hole locations onto the vertical mounting strips in the
4.
cabinet, as shown on the template. The marks will locate the mounting
holes of the rail brackets and front panel.
Attach the front bracket to the front cabinet vertical mounting strip
5.
using two screws. Attach the rear bracket to the rear cabinet vertical
mounting strip.
Repeat steps 4 and 5 to mount the second rail bracket.
6.
Installing the Processor Drawer 9
