Appendix A:
DLHD Specifications

Fixture mechanical, electrical, optical and component specifications are listed.

Mechanical

Fixture Dimensions: 594mm x 690mm x 950mm (23.4in x 24.8in x 38.4in)
Weight: 63.5 kg (140 lbs)
Road Case Dimensions: 711mm x 737 mm x 1168mm ( 28in x 29 in x 46 in)
Weight (Fixture + Roadcase): 118 kg (260 lbs)
254 mm
10.0 in
DLHD Digital Light User Manual
254 mm
10.0 in
594 mm
23.4 in
556 mm
22.3 in
597mm
23.5 in
238 mm
9.3 in
577 mm
22.7 in
191 mm
7.4 in
690 mm
24.8 in
353 mm
13.9 in
521 mm
20.5 in
APPENDIX A
DLHD Specifications
950 mm
37.4 in
414 mm
16.3 in
285
