３-５. Beginner kit's parts
1
~
motor
AX-12×4
F1 ×4
F8 ×2
F9 ×3
BU ×6
SMPS
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 ×150
S1 ×150
S2 ×20
S3 ×20
S4 ×20
S5 ×20
S-B ×10
4
motor
AX-S1
×1
F2 ×4
F3 ×12
F10 ×10
WA ×6 SP1 ×4
Serial Cable
CM-5
×1
F4 ×2 F5 ×1
F11 ×2 F12 ×2
SP2 ×4 Sticker ×32
QuickStart
95
×1
ADAPTOR-CM5
F6 ×4
F13 ×4 F14 ×4
Fuse ×1
CD
×2
CABLE-6
CABLE-10 ×3
×2
CABLE-14
CABLE-18 ×1
×1
CABLE-20
