Beginner Level Robot Series
(2) Assembling
Shoulder : 2 sets Hand : 2sets Head
Step 1 Step 2 Step 3
※Assemble 2 sets in a same ※Assemble 2 sets in a same
style. style.
S1 : 4pcs
N1 : 4pcs
S1 : 4pcs
F3
S1
: 4pcs
F1
F9
F3
N1 : 4pcs F3
Upper part of body Assembly
Step 4
※Insert nuts
N1 : 12pcs
N1 : 8pcs
1
motor
2
Step 3 motor
Step 1
Step 1
S1 : 28pcs
Step 2
WA : 2pcs
S-B : 2pcs Step 2
BU : 2pcs
※Check assembly point
79
