２-２-５. Pan Tilt
Let's build a pan tilt robot that can be controlled with the pan(right and left) and tilt(up and down)
buttons.
(1) Necessary parts
BU × 1
3 4
motor motor
WA × 1
AX-12 × 2 CM-5 F2 × 1 F3 × 3
ADAPTOR-CM5
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 × 20
CABLE-14 × 2
S1 × 28
S-B × 1
