２-２-９. Obstacle Detection Car
Let's build a car that detects an obstacle with a sensor and that avoid the obstacle
automatically.
(1) Necessary parts
1 2 3
motor motor motor motor
AX-12 × 4
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 × 48
S1 × 48
S2 × 16
4
AX-S1
F3 × 6 F13 × 4
CM-5
F14 × 4
57
ADAPTOR-CM5
Sticker × 10
CABLE-6 × 2
CABLE-14
CABLE-10
× 2
× 1
