Beginner Level Robot Series
(2) Assembling
Left Wheel : 2 sets
Step 1
※Assemble 2 sets using
※Insert nuts
N1 : 4pcs
2 4
motor motor
F3
※Assemble taking
note of the inserted
location of nuts .
Joint
Step 3
F3
N1 : 4pcs
S1 : 4pcs
2 and 4
motor motor
※Attach nut stickers :
Make sure nuts do
not come off.
N1 : 4pcs
Sticker
:2pcs
S1 : 4pcs
F13
Head
Step 4
※Insert nuts
: 2pcs
ADAPTOR-CM5
Right Wheel : 2 sets
Step 2
※Assemble 2 sets using
※Insert nuts
N1
: 4pcs
1 3
motor motor
F3
S1 : 4pcs
F13
F14
F14
S2
S2
: 4pcs
: 4pcs
N1 : 8pcs
Step 3
58
and
1 3
motor motor
※Attach nut stickers :
Make sure nuts do
not come off.
N1 : 4pcs
Sticker
:2pcs
※Assemble taking
note of the inserted
location of nuts .
※Attach nut stickers :
Make sure nuts do not
come off.
Sticker
:2pcs
N1 : 4pcs
S1 : 8pcs
