Beginner Level Robot Series
(3) Check Assembly
You should confirm whether assembled uprightly before operate.
Step 1 Download "Check Assembly"file which is behavior control program
(In CD, Applied Robots\Beginner\Universal Guage\CheckAssembly(Universal
※Refer to "How to download Behavior Control Program" from "2-1-2 Downloading Robot
Programs"
Step 2 Operate online robot.
※Refer to "Online Robot Activation" from "2-1-3. Operating the Robots"
Step 3 Compare the execution screen with the image below. If different, check Dynamixel ID
and cable wiring using the assembly diagram.
Step 4 Whenever
below. By pressing
the figure.
※Whenever U button is pressed LED is on in the order shown
※For ID of Dynamixel refer to the figure below.
U button of CM-5 is pressed, Dynamixel LED will be on in the order shown
U button of CM-5 in order, compare the Dynamixel location of the robot with
U button
motor
LED on
2
26
Guage).bpg)
comparison part
2
motor
