Table 8-7 IPv6 Section (continued)
Message
LINK-LOCAL:
STATELESS:
DHCPV6:
MANUAL:

IPX/SPX Protocol Information

Information in this section of the Jetdirect configuration page is described in
Configuration
Table 8-8 IPX/SPX Configuration Information
Message
STATUS:
PRIMARY FRAME TYPE:
NETWORK
FRAME TYPE
126 Chapter 8 HP Jetdirect Configuration Pages
Description
An error code and message is displayed if the print server is not ready. For more
information, see
Specifies the IPv6 Link Local address configured on the print server.
Not Configured: A link local address has not been configured.
Specifies IPv6 Stateless addresses configured on the print server.
Not Configured: A Stateless address has not been configured.
Specifies the print server IPv6 stateful address configured by a DHCPv6 server.
Not Configured: A stateful address has not been configured.
Specifies an IPv6 address manually configured on the print server, for example, through
the printer control panel or the embedded Web server.
Not Configured: An address has not been manually configured.
Information. For error messages, see
Description
Indicates the current IPX/SPX protocol status.
READY: Indicates the HP Jetdirect print server is awaiting data over IPX/SPX.
DISABLED: Indicates that IPX/SPX was manually disabled.
INITIALIZING: Indicates that the print server is registering the node address or name.
An additional status message may also be displayed.
An error code and message is displayed if the print server is not ready. For more
information, see
Specifies the frame type selection on the Jetdirect print server.
AUTO SELECT: The print server automatically senses and limits the frame type to the
first one detected.
EN_8023: Limits the frame type to IPX over IEEE 802.3 frames. All others will be
counted and discarded.
EN_II: Limits the frame type to IPX over Ethernet frames. All others will be counted and
discarded.
EN_8022: Limits the frame type to IPX over IEEE 802.2 with IEEE 802.3 frames. All
others will be counted and discarded.
EN_SNAP: Limits the frame type to IPX over SNAP with IEEE 802.3 frames. All others
will be counted and discarded.
The first column (Network) indicates the network number associated with a protocol
frame type used for communication between a server and the HP Jetdirect print server.
UNKNOWN: Indicates that the HP Jetdirect print server is still trying to determine which
network number to use.
Table 8-12 Error Messages.
Table 8-12 Error
Table 8-12 Error Messages.
Table 8-8 IPX/SPX
Messages.
