Table 8-3 Security Settings (continued)
Message
SNMP Set Cmty Name:
Access List:
Secure Web:

Network Statistics

Information in this section of the Jetdirect configuration page is described in
Table 8-4 Network Statistics
Message
TOTAL PACKETS RECEIVED:
UNICAST PACKETS RECEIVED:
BAD PACKETS RECEIVED:
FRAMING ERRORS RECEIVED:
TOTAL PACKETS TRANSMITTED:
UNSENDABLE PACKETS:
122 Chapter 8 HP Jetdirect Configuration Pages
Description
3-a/np: SNMP v.1 and v.2c are disabled. SNMP v.3 is enabled with the minimum
security of authentication enabled ("a") but no privacy ("np").
3-a/p: SNMP v.1 and v.2c are disabled. SNMP v.3 is enabled with the minimum security
of authentication ("a") with privacy ("p") enabled.
Specifies whether an SNMP set community name has been configured on the HP
Jetdirect print server. An SNMP set community name is a password for write access to
SNMP control functions (SNMP SetRequests) on the HP Jetdirect print server.
Not Specified: An SNMP set community name has not been set.
Specified: A user-specified SNMP set community has been set.
(IPv4 only) Identifies whether a host access control list is configured on the HP Jetdirect
print server. A host access control list specifies the IP address of individual systems, or
IP network of systems, that are allowed access to the print server and device.
Specified: A host access list is configured on the HP Jetdirect print server.
Not Specified: A host access list is not configured on the print server. All systems are
allowed access.
Specifies the use of encrypted communications between a browser and the HP Jetdirect
embedded Web server.
Optional (HTTPS/HTTP): Allows unencrypted communications using standard HTTP
ports, as well as encrypted communications using HTTPS (secure HTTP).
HTTPS Required: Only encrypted communications on HTTPS is allowed.
Description
Total number of frames (packets) received by the HP Jetdirect print server without error.
This includes broadcast, multicast packets, and packets specifically addressed to the
print server. This number does not include packets specifically addressed to other
nodes.
Number of frames specifically addressed to this HP Jetdirect print server. This does not
include broadcasts or multicasts.
Total number of frames (packets) received with errors by the HP Jetdirect print server.
Maximum of CRC (Cyclic Redundancy Check) errors and framing errors. CRC errors
are frames received with CRC errors. Framing errors are frames received with
alignment errors. A large number of framing errors could indicate a cabling problem with
your network.
Total number of frames (packets) transmitted without error.
Total number of frames (packets) not successfully transmitted because of errors.
Table 8-4 Network Statistics.
