TCP/IP Settings

In firmware version V.31.xx, the TCP/IP Settings menu combines all TCP/IP configuration parameters,
some of which had been formerly contained in the Network Settings menu. You can access the
following tabs:
●

Summary

●
Network Identification
●
TCP/IP(v4)
●
TCP/IP(v6)
●
Config Precedence
●
Advanced
Summary
This tab provides a summary of the TCP/IP configuration. Items on this page are listed below.
Table 4-3 TCP/IP Summary tab
Item
Host Name
IPv4 status
Fully Qualified Domain Name (IPv4/
IPv6)
IPv4 Address
Config By
DHCP Lease Time
IPv6 Status
Fully Qualified Domain Name (IPv6
only)
IPv6 Address list
66 Chapter 4 HP Jetdirect Embedded Web Server (V.34.xx)
Description
Specifies the IP host name assigned to the device and stored on the HP Jetdirect print
server.
To configure a host name, see the Network Identification tab.
Indicates the status of IPv4 operation. IPv4 cannot be disabled from the embedded Web
server in this release.
The fully qualified domain name (FQDN) consists of the device's host name and domain
name. Unless the network administrator segments domains into separate IPv4 and IPv6
hosts, the FQDN can be used on either IPv4 or IPv6 networks simultaneously.
Identifies the IPv4 address, subnet mask and default gateway for the print server.
Specifies how the IPv4 parameters were configured: DHCP, BOOTP, Manual, or Auto
IP.
If DHCP is used for configuration, the duration of the DHCP IP address lease (in
seconds) for the print server will be displayed.
Indicates the status of IPv6 operation. IPv6 can be enabled or disabled through the
embedded Web server.
The fully qualified domain name (FQDN) consists of the device's host name and domain
name. Depending on the network architecture, it can be the same as, or different from,
the printer's IPv4 FQDN. If assigned, it applies to the IPv6 network only.
IPv6 addresses configured on the print server are listed. For each address, the following
items are specified:
● Prefix length: identifies the number of bits that comprise the fixed portion of the
address. Typically, it is 64 and identifies network/subnet portion of the address.
●
Config By: identifies how the address was configured, such as auto-configuration
through link-local addressing, by a Router, by a DHCP(v6) server, or configured
manually.
