Table C-1 HP Jetdirect Control Panel Menu (continued)
Menu Item
162 Appendix C The HP Jetdirect Control Panel Menu (V.34.xx)
Submenu Options Additional Options
EMBEDDED TESTS
LAN HW TEST
HTTP TEST
SNMP TEST
DATA PATH TEST
SELECT ALL TESTS Use this item to select all available embedded tests.
EXECUTION TIME
[H]
EXECUTE
PING TEST DEST TYPE
DEST IP
PACKET SIZE
Description of settings
Embedded tests help to identify whether a network fault
is internal or external to the printer/MFP. Use an
embedded test to check hardware and communication
paths on the print server. After you select and enable a
test and set the execution time, you must select
EXECUTE to initiate the test.
Depending on the execution time, a selected test will run
continuously until either the printer is turned off, or an
error occurs and a diagnostic page is printed.
CAUTION This embedded test will erase
your TCP/IP configuration.
This test performs an internal loopback test. An internal
loopback test will send and receive packets only on the
internal network hardware. There are no external
transmissions on your network.
Select YES to choose this test, or No to not choose it.
This test checks operation of HTTP by retrieving
predefined pages from the printer/MFP device, and tests
the embedded Web server.
Select YES to choose this test, or No to not choose it.
This test checks operation of SNMP communications by
accessing predefined SNMP objects on the printer/MFP
device.
Select YES to choose this test, or No to not choose it.
This test helps to identify data path and corruption
problems on a PostScript printer/MFP device. It sends a
predefined PostScript file to the printer/MFP device,
However, the test is paperless; the file will not print.
Select YES to choose this test, or No to not choose it.
Select YES to choose all tests. Select No to not run all
tests.
Use this item to specify the length of time (in hours) that
an embedded test will be run. You may select a value
from 1 to 60 hours. If you select zero (0), the test will run
indefinitely until an error occurs or power is turned off.
Data gathered from the HTTP, SNMP, and Data Path
tests will be printed after the tests have completed,
Choose one of the following:
YES: Initiate the selected test.
NO: Do not initiate the selected test.
This test is used to check network communications. This
test sends link-level packets to a remote network host,
