HP Jetdirect J7974E Administrator's Manual page 54

Table 3-3 Telnet Commands and Parameters (continued)
security-reset
TCP/IP Main
host-name
ip-config
ipsec-config
firewall-config
ip
subnet-mask
default-gw
44 Chapter 3 TCP/IP Configuration
2: Disable forced redirection to HTTPS. Both HTTP and HTTPS communications can be
used.
Reset security settings on the print server to factory default values. 0 (default) does not
reset, 1 resets the security settings.
Alphanumeric string (up to 32 characters), to assign or change the name of the network
device. For example,
"host-name printer1" assigns the name "printer1" to the device. The default host name is
NPIxxxxxx, where xxxxxx are the last six digits of the LAN hardware (MAC) address.
Specify the configuration method:
manual: The print server will wait for IP parameters using manual tools (such as Telnet,
embedded Web server, control panel, installation/management software). Status will be
User Specified.
bootp: The print server will send BOOTP requests on the network for dynamic IP
configuration.
dhcp: The print server will send DHCP requests on the network for dynamic IP
configuration.
auto_ip: The print server will be automatically configured with a unique link-local address
169.254.x.x.
The ipsec-config command is supported on print servers and printers that support both
IPsec and Firewall configurations. The firewall-config command is supported on print
servers that do not support IPsec, but allow Firewall configuration.
Use these commands to disable IPsec or Firewall operation on the print server after IPsec/
Firewall policies have been configured and enabled. IPsec/Firewall operation cannot be
enabled by this command; if IPsec/Firewall policies are enabled, the status will be "read
only".
0: Disable IPsec/Firewall operation, if it is enabled.
1: (Read Only) Indicates IPsec/Firewall policies are configured and enabled. Use the
embedded Web server to configure and enable IPsec/Firewall policies.
IP address for the print server, in dotted notation. For example:
ip-config manual ip 192.168.45.39
where ip-config specifies manual configuration and ip manually sets the IP address
192.168.45.39 on the print server.
Specifying 0.0.0.0 clears the IP address.
If you exit and save a new IP address, it must be specified on the next Telnet connection.
A value (in dotted notation) that identifies the network and host portions of an IP address
in received messages. For example,
subnet-mask 255.255.255.0
stores the subnet mask value 255.255.255.0 on the print server. The value 0.0.0.0 disables
the subnet mask.
The IP address of a default gateway, in dotted notation. For example,
default-gw 192.168.40.1
ENWW
