Tcp/Ip(V4) - HP Jetdirect J7974E Administrator's Manual

Table 4-4 TCP/IP Network Identification tab (continued)
Item
Bonjour

TCP/IP(v4)

The TCP/IP(v4) tab allows you to configure basic IPv4 settings on the print server. For additional
parameters, see the Advanced tab.
Table 4-5 TCP/IP(v4) tab
Item
IP Configuration Method
IP Address
Subnet Mask
Default Gateway
68 Chapter 4 HP Jetdirect Embedded Web Server (V.34.xx)
Description
Alternate: Specify the IP address to be used for WINS if the preferred WINS Server is
unavailable.
Use this section to specify the Bonjour Service Name (formerly listed as Multicast
Domain Name System, or mDNS, Service Name), or to identify the assigned Bonjour
Domain Name.
● Bonjour Service Name: This name is persistent and is used to resolve a particular
device or service if socket information (such as the IP address) changes from
session to session.
The default service name is the printer model along with the last six digits of the
LAN Hardware (MAC) address. To change the name assigned to this device or
service, enter an alphanumeric string of up to 64 ASCII characters.
●
Bonjour Domain Name: (Read-only parameter) Specifies the Bonjour domain name
assigned to the device, in the form <host name>.local. If a host name has not been
assigned, the default host name NPIxxxxxx is used, where xxxxxx are the last 6
digits of the LAN hardware (MAC) address.
Description
Selects the method that the HP Jetdirect print server will use for its IP configuration parameters:
BOOTP (default), DHCP, Manual, or Auto IP.
For BOOTP or DHCP, the IP parameters will be automatically configured by a BOOTP or DHCP
server each time the print server is powered on.
If you select Manual, then basic IP parameters can be manually entered using this Web page,
or using other available tools.
If you select Auto IP, then a unique link-local address 169.254.x.x will be assigned.
For more information, see TCP/IP
Use this field to manually assign the Internet Protocol address on the HP Jetdirect print server.
The IP address is a four byte (32-bit) address in the form "n.n.n.n", where 'n' is a number from
0 to 255.
An IP address uniquely identifies a node on a TCP/IP network. Duplicate IP addresses on a
TCP/IP network are not allowed.
If subnetting is used, use this field to manually assign a subnet mask. A subnet mask is a 32-
bit number that, when applied to an IP address, determines which bits specify the network and
subnet, and which bits uniquely specify the node.
Identifies the IP address of a router or computer that is used to connect to other networks or
subnetworks.
Configuration.
