B.8

Video Connector

The video connector is a 15-pin mini D-sub connector located on the back panel.
FIGURE B-8
TABLE B-9
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
5
10
15
Video Connector J37 Pin Configuration
Video Connector J37 Pin Assignments
Signal
Red
Green
Blue
Gnd
NC
Gnd
Gnd
Gnd
NC
Gnd
Gnd
SDA
Horizontal sync
Vertical sync
SCL
1
6
11
Description
Red video signal
Green video signal
Blue video signal
Ground
Not connected
Ground for red video signal
Ground for green video signal
Ground for green video signal
Not connected
Ground
Ground
Bidirectional data
Horizontal synchronizing signal
Vertical sync clock
Data clock
Appendix B
Signal Descriptions
B-11
