Table B-1 Power Supply Connector J501 Pin Assignments - Sun Microsystems Sun Blade 100 Service Manual

TABLE B-1
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
B-2 Sun Grover Service Manual • October 2000
Power Supply Connector J501 Pin Assignments
Signal
+3.3V
+3.3V
Gnd
+5V
Gnd
+5V
Gnd
PWR_OK
5VSB
+12V
+3.3V
-12V
Gnd
PS_ON
Gnd
Gnd
Gnd
-5V
+5V
+5V
Description
+3.3 VDC
+3.3 VDC
Chassis ground
+5 VDC
Chassis ground
+5 VDC
Chassis ground
Power okay
+12 VDC
+3.3 VDC
-12 VDC
Chassis ground
Power supply on
Chassis ground
Chassis ground
Chassis ground
-5 VDC
+5 VDC
+5 VDC
