2. Using a No. 2 Phillips screwdriver, replace the three screws securing the smart
card reader to the peripheral assembly (
3. Position the peripheral assembly into the chassis, aligning the three holes on the
assembly with the three screws on the chassis (
4. Slide the assembly forward until it stops.
5. Using a No. 2 Phillips screwdriver, tighten the three screws securing the
peripheral assembly to the chassis.
6. Connect the following:
Diskette drive data cable
Diskette drive power cable
Smart card reader cable
Note – Ensure that the cable assembly connectors are properly oriented by aligning
the connector keys.
7. If you removed any PCI cards, reinstall them on the riser board.
See Section 8.4.2 "Replacing a PCI Card" on page 8-13.
8. Detach the wrist strap, replace the system cover, and power on the system as
described in Chapter 9 "Finishing Component Replacement."
7.3

Hard Drives

To remove and replace a primary (master) hard drive, proceed as follows.
7.3.1

Removing a Primary Hard Drive

1. Power off the system, remove the system cover, and attach an antistatic wrist strap
as described in Chapter 5 "Preparing for Component Removal and Replacement."
Caution – Use proper ESD grounding techniques when handling components. Wear
an antistatic wrist strap and use an ESD-protected mat. Store ESD-sensitive
components in antistatic bags before placing them on any surface.
2. Lift the spring-loaded latch upward to release the hard drive tray from the chassis
(
FIGURE 7-3
).
).
FIGURE 7-2
FIGURE 7-1
Chapter 7 Removing and Replacing Storage Devices
.
)
7-5
