Sun Blade™ 150
DIMM Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Blade 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems Blade 150

Summary of Contents for Sun Microsystems Blade 150

  • Page 1 Sun Blade™ 150 DIMM Installation Guide...
  • Page 2 Sun, Sun Microsystems, the Sun logo, AnswerBook2, docs.sun.com, Sun Blade, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and in other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.

  • Page 3: Verifying The Current Dimm Configuration

    2. Read the banner screen on your monitor to verify the amount of memory already installed in your system. Note – The Sun Blade 150™ system reports the CPU as an UltraSPARC™ IIe processor. The CPU in your system is an UltraSPARC IIi processor.

  • Page 4: Supported Dimm Configurations

    Sun Blade 150, UltraSPARC-IIe 650 MHz, Keyboard Present. Copyright 1998-2003 Sun Microsystems, Inc. All rights reserved. OpenBoot 4.6, 128 MB memory installed, Serial #54528. Ethernet address 8:0:20:1a:b3:c8, Host ID: 7200d500. Banner Screen Example FIGURE 1 Supported DIMM Configurations You can install one, two, three, or four DIMMs.

  • Page 5: Removing The System Cover

    The system shutdown menu is displayed. b. Select Shutdown. The system performs internal shutdown procedures. To perform an immediate power off, press and hold the power switch for four seconds before releasing it. Caution – The immediate power-off method does not perform an orderly shutdown of the operating system and data might be lost.

  • Page 6: Attaching An Antistatic Wrist Strap

    Caution – Pressing the power switch does not remove all power from the system. A standby voltage remains in the power supply. To remove all power from the system, you must disconnect the system power cord. 3. At the system back panel, remove the two screws that secure the cover.
  • Page 7 Power switch Preparing for DIMM Installation FIGURE 2...

  • Page 8: Installing The Dimms

    DIMMs in this system. Verify with your Sun sales or service representative that the DIMMs you order have been certified by Sun for the Sun Blade 150 system. 1. Power off the system, remove the cover, and attach an antistatic wrist strap as described in “Preparing for Installation”...
  • Page 9 Unpacking the DIMM FIGURE 3 2. Push apart the ejection levers at each end of an empty DIMM connector on the motherboard ( FIGURE 5 3. Unpack the DIMM, holding it only by the edges ( FIGURE 3 Note – When installing additional DIMMs, first fill slot 1 (the connector closest to the motherboard edge), then fill towards the CPU (...
  • Page 10 5. Press firmly on both top corners of the DIMM at the same time until the DIMM is fully seated. Caution – Seating the DIMM into a slot unevenly can cause short circuits that damage the system. Ensure that all contacts engage at the same time.
  • Page 11 DIMM Installation Order FIGURE 4...

  • Page 12: Finishing Component Installation

    Alignment notch Correct DIMM Insertion FIGURE 5 7. Repeat Steps 3 through 6 until you are finished installing the additional DIMMs. 8. Complete the next section, “Finishing Component Installation” on page 10. Finishing Component Installation 1. Reconnect the system power cord ( FIGURE 2 2.
  • Page 13 5. Replace the two screws that secure the rear of the cover to the system chassis. 6. Reconnect the monitor cable and cables from any other external devices to the system. Verifying That the System Recognizes the New DIMMs 1. Turn on power to the monitor and to all external devices. 2.
  • Page 14 The Sun Blade 150 Service Manual, 816-4379, contains information on DIMMs in the following sections: Chapter 4, “Troubleshooting” Chapter 8, “Removing and Replacing Components” Appendix C, Section C.9, “Memory Architecture” Updates to all Sun Blade 150 documents can be found in the Sun Blade 150 Product Notes, 816-1163.

  • Page 15: Accessing Sun Blade 150 Documentation

    Contacting Sun Technical Support If you have technical questions about this product that are not answered in this document or other Sun Blade 150 workstation documents go to: http://www.sun.com/service/contacting/ Sun Welcomes Your Comments Sun is interested in improving its documentation and welcomes your comments and suggestions.
  • Page 17 X/Open Company, Ltd. Sun, Sun Microsystems, le logo Sun, AnswerBook2, docs.sun.com,Sun Blade, et Solaris sont des marques de fabrique ou des marques déposées de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays. Toutes les marques SPARC sont utilisées sous licence et sont des marques de fabrique ou des marques déposées de SPARC International, Inc.
  • Page 18 SunMicrosystems,Inc. 4150 Network Circle Santa Clara, CA 95054 USA 650-960-1300 Fax 650-969-9131 Part Number: 816-5370-11 April 2003, Revision A...
