Error Environment - BONFIGLIOLI Act 201 Operating Instructions Manual

19.2
The parameters of the error environment help troubleshooting both in the settings of
the frequency inverter and also in the complete application. The error environment
documents the operational behavior of the frequency inverter at the time of the last
four faults.
No.
330 DC link voltage
331 output voltage
332 Stator Frequency
333
335 Phase Current Ia
336 Phase Current Ib
337 Phase Current Ic
338 R.m.s Current
339 Isd / Reactive Current
340 Isq / Active Current
341 Rotor Magnetizing Current
342 Torque
343 Analog Input MFI1A
346 Analog Output MFO1A
349 Repetition Frequency Output
350 Status of Digital Inputs
351 Status of Digital Outputs
352 Time since Release
353 Heat Sink Temperature
354 Inside Temperature
355 Controller Status
356 Warning Status
Table "Error Environment" continued on next page.
06/07
06/07

Error Environment

Description
Encoder 1 Frequency
Operating Instructions ACTIVE
Operating Instructions ACTIVE
Error Environment
Direct voltage in the DC link.
Calculated output voltage (motor voltage) of the
frequency inverter.
The output frequency (motor frequency) of the
frequency inverter.
Calculated from the data on encoder 1, the
of Pole Pairs
373 and the encoder signal.
Measured current in motor phase U.
Measured current in motor phase V.
Measured current in motor phase W.
Calculated effective output current (motor cur-
rent) of the frequency inverter.
Current component forming the magnetic flux or
the calculated reactive current.
Current component forming the torque or the
calculated active current.
Magnetizing current relative to the rated motor
parameters and the operating point.
Torque calculated from the voltage, the current
and the control variables.
Input signal on multifunctional input 1 in
tion Mode
452 - analog input.
Output signal on multifunctional output 1 in
eration Mode
550 – analog.
Signal at repetition frequency output according
Operation Mode
to
Decimally coded status of the six digital inputs
and of multifunctional input 1 in
452 - digital input.
Decimally coded status of the two digital outputs
and of multifunctional output 1 in
Mode
550 – digital.
The time of the error in hours (h), minutes (m)
and seconds (s) after the release signal:
sec
hhhhh:mm:ss . /
10
Measured heat sink temperature.
Measured inside temperature.
The reference value signal is limited by the con-
troller coded in the controller status.
The warning messages coded in warning status.
Function
Opera-
550 – repetition frequency.
Operation Mode
Operation
sec sec .
/ /
100 1000
No.
Op-
199
199
