Harmonic ProView 7000 User Manual page 77

Chapter 7 Device Configuring Using EMS
Modulation and FEC – Sets the modulation scheme and forward error correction for the
■
receiver.
DVB-S options:
❑
• Automatic – modulation and FEC set by the device
• QPSK 1/2
• QPSK 2/3
• QPSK 3/4
• QPSK 5/6
• QPSK 7/8
DVB-S2 options:
❑
• VCM
• QPSK 1/4
• QPSK 1/3
• QPSK 2/5
• QPSK 1/2
• QPSK 3/5
• QPSK 2/3
• QPSK 3/4
• QPSK 4/5
• QPSK 5/6
• QPSK 8/9
• QPSK 9/10
• 8PSK 3/5
• 8PSK 2/3
• 8PSK 3/4
• 8PSK 5/6
• 8PSK 8/9
• 8PSK 9/10
• 16APSK 2/3
• 16APSK 3/4
• 16APSK 4/5
• 16APSK 5/6
• 16APSK 8/9
• 16APSK 9/10
5. A license is required for 16APSK modulation. Only available with certain hardware configurations, see
Features.
© 2012 Harmonic Inc.
4
– Variable Coding Modulation format / Automatic
4
4
4
5
5
5
5
5
5
77
Physical Input Ports and Slots
4
B.6 Front End Card
ProView 7000 v.2.6, Rev. E
