Chapter 6 Remote Management using EMS
Refreshing the EMS Screen
Physical Input port box
Multiplex Input box
Multiplex and
Physical Output port box
decoding Output box
EMS Menu
EMS Toolbar
Box expand/
collapse control
Device box
Box border
Device stream tab
Alarm report tab
Alarm history tab
Status bar
Figure 6–2: ProView 7000™ EMS Graphical User Interface
© 2012 Harmonic Inc.
71
ProView 7000 v.2.6, Rev. E
